DANFOSS Decentral Drive FCD 302 series 0.75 KW | 130B7941
- Power Rating: 0.75 KW / 1.0 HP
- Phase: Three phase
- Operating voltage: 380-480 VAC
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
DANFOSS Decentral Drive FCD 302 series 0.75 KW | 130B7941
DANFOSS Decentral Drive
DANFOSS Decentral Drive Supplier in Bangladesh
DANFOSS Decentral Drive AT A GLANCE
The VLT® Decentral Drive FCD 302 is a complete drive designed for decentral mounting. It can be mounted on the machine/wall – close to the motor – or directly on the motor. The decentral design reduces the need for central control panels and space-consuming motor control cabinets are eliminated. In addition, the need for long screened motor cables is significantly reduced.
Technical Details
| Gross weight | 9.37 Kilogram | ||
| Net weight | 8.705 Kilogram | ||
| Volume | 40.163 Liter | ||
| EAN | 5710107948710 |
| Product Group | FCD | VLT® DecentralDrive FCD | |
| VLT Series | 302 | 302 | |
| Power Rating | PK75 | 0.75 kW / 1.0 HP | |
| Mains Voltage | T4 | 380-480VAC (Three phased) | |
| Enclosure | B66 | Standard Black IP66/NEMA4X | |
| RFI Filter | H1 | RFI Class A1/C2 | |
| Brake | S | Brake chop. + mech. brake | |
| Hardware Configuration | 1 | Compl. small stand alone | |
| Brackets | F | 40 mm brackets | |
| Threads | M | Metric threads | |
| Switch Option | F | Service switch motor side | |
| Display | C | With display connector | |
| Sensor Plugs | E | Direct mount 4xM12 | |
| Motor Plug | X | No motor plug | |
| Mains Plug | X | No mains plug | |
| Fieldbus Plug | X | No fieldbus plug | |
| Reserved | X | Reserved | |
| A Option | AX | No fieldbus option | |
| B Option | BX | No B option | |
| Reserved for SW | XXXXX | Reserved for SW | |
| D Option | DX | No option | |
| FCD302 Frame Size | MF1 | (MF1) MF1 | |
| Modelcode01 | FCD302PK75T4B66H1S1FMFCEXXXX | ||
| Modelcode02 | AXBXXXXXXDX | ||
| Product Catalog | NO_VIEW | NO VIEW | |
| ECCN EU | Y901 | Y901 | |
| ECCN US | 3A999.a | 3A999.a | |
| Calculated Gross Weight [kg] | 9.37 | ||
| Calculated Net Weight [kg] | 8.705 |
Datasheet: PDF
