Description

Autonics PSAN-01CA-RC1/8 – Digital Display Pressure Sensors

Technical Specifications:

Applicable fluid	(Pneumatic type) Air, Non-corrosive gas
Pressure port direction	Rear fitting
Pressure port	Rc1/8
Connection type	Connector type(connector type cable: 2m)
Pressure type	Standard pressure
Rated pressure range	0.0 to 100.0kPa
Display pressure unit	MPa, kPa, kgf/cm², bar, psi
Control output_NPN open collector	NPN open collector
Option input/output	Current output(DC4-20mA)
Power voltage	12-24VDC  ±10%(ripple P-P: max. 10%)
Current consumption	Voltage output type: Max. 50mA Current output type: Max. 75mA
Protection structure	IP40
Control output_Hysteresis	Min. display interval
Control output_Repeat error	±0.2% F.S. ±Min. display interval
Control output_Response time	Selectable 2.5ms, 5ms, 100ms, 500ms, 1000ms
Environment_Ambient temperature	-10 to 50℃, storage: -20 to 60℃
Environment_Ambient humidity	30 to 80% RH, storage: 30 to 80% RH
Material	Front, Rear case: Polycarbonate, Pressure port: Nickel Plated Brass
Weight	Approx. 165g(approx. 80g)

※In case of using M5 port, use PSO-Z01 (M5 Gender) together.
※In hysteresis output mode, detection difference is variable.
※It is allowed to select one analog output type only.
※The weight includes packaging. The weight in parenthesis is for unit only.
※The unit is sealed structure. It is based on atmospheric pressure 101.3kPa.
※F.S: Rated pressure.
※There may be ±1-digit error in hysteresis by pressure unit calculation error.
※The temperature or humidity mentioned in Environment indicates a non freezing or condensation.

Data Sheet: PDF
