AUTONICS Inductive Proximity Sensors | PRFDACM30-12DP-K
- Sensing range (max.): 12 mm
- Connection type: M12 plug connector
- Switching output: PNP
- Output function: NO
- Switching frequency: 10 Hz
- Installation type: Flush
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
AUTONICS Inductive Proximity Sensors | PRFDACM30-12DP-K
AUTONICS Inductive Proximity Sensors
AUTONICS Inductive Proximity Sensors Supplier in Bangladesh
PRFD-K
Cylindrical Inductive Full-Metal Long-Distance Proximity Sensors (Factor 1)
The PRFD-K series full-metal cylindrical inductive proximity sensors feature factor 1 sensing to ensure equal sensing distances for iron and aluminum. This enables stable detection in manufacturing lines with both iron and aluminum targets. The sensors feature full-metal housing and sensor heads made of stainless steel 303 and can be applied with harsh environments.
PRFD-K AT A GLANCE
- Factor 1 sensing with equal detection distance for iron, aluminum and brass
(M30 models offer factor 1 sensing for aluminum, iron and brass.) - High durability against contact with workpieces or wire brushes (sensor head/housing: stainless steel)
- Reduced risk of malfunction caused by aluminum chips
- 2-color LED indicator for easy status monitoring
- Oil resistant cable
- Protection structure
- Cable type, cable connector type: IP66, IP67
- Connector type: IP66, IP67, IP67G, IP68
- PTFE coating prevents malfunctions caused by welding spatter (spatter-resistant PRFDA□ models)
Technical details-
| Installation | Flush |
|---|---|
| Sensing side diameter | Ø30mm |
| Sensing distance | 12mm |
| Hysteresis(distance) | Max. 15% of sensing distance |
| Standard sensing target | 54×54×1mm(iron) |
| Response frequency | 10 Hz |
| Indicator | Stable indicator (green), unstable indicator (orange), Abnormal detect indicator (cross-flashing green, orange) |
| Unit weight (packaged weight) | ≈ 85 g (≈ 140 g) |
| Power voltage | 10 – 30 VDC (ripple P-P: ≤ 10 %) |
| Current specification | Current consumption: Max. 20mA |
| Control output | Max. 100mA |
| Residual voltage | ≤ 2.5 V |
| Protection circuit | Surge protection circuit, output short over current protection circuit, reverse polarity protection circuit |
| Insulation resistance | ≥ 50 MΩ (500 VDC megger) |
| Dielectric strength | Between the charging part and the case: 1,000 VAC~ 50/60 Hz for 1 minute |
| Vibration | 1.5 mm amplitude at frequency of 10 to 55Hz in each X, Y, Z direction for 2 hours |
| Shock | 1,000 m/s² (≈ 100 G) in each X, Y, Z direction for 10 times |
| Environment_Ambient temperature | -25 to 70 ℃, storage: -25 to 70 ℃ (no freezing or condensation) |
| Environment_Ambient humidity | 35 to 95 %RH, storage: 35 to 95 %RH (no freezing or condensation) |
| Protection structure | IP66, IP67 (IEC standard), IP67G (JEM standard), IP68 |
| Connection | Connector models |
| Connector type | M12 plug connector |
| Material | Case / Nut: stainless steel 303 (SUS303, PTFE coated), rear cap: stainless steel 303 (SUS303), washer: stainless steel 304 (SUS304), sensing side: stainless steel 303 (SUS303, PTFE coated) |
※ Use accessories (nut, washer) made of SUS. Or, sensing distance cannot be guaranteed.
※ The response frequency is the average value. The standard sensing target is used and the width is set as 2 times of the standard sensing target, 1/2 of the sensing distance for the distance.
※ UL approved surrounding air temperature 60 ℃
※ Thickness: DIA. of sensing side Ø 12 mm, Ø 18 mm: 0.4 mm / DIA. of sensing side Ø 30 mm: 0.5 mm
Datasheet: PDF
