AUTONICS PRDCMLT30-25DC

AUTONICS Inductive Proximity Sensors | PRDCMLT30-25DC

  • Sensing range (max.): 25 mm
  • Connection type: M12 connector
  • Switching frequency: 100 Hz
  • Installation type: Non Flush



For Price Call: 01329727092
Email: sales@voltecbd.com
Category:
Tags:

Description

AUTONICS Inductive Proximity Sensors | PRDCMLT30-25DC

AUTONICS Inductive Proximity Sensors

AUTONICS Inductive Proximity Sensors Supplier in Bangladesh

PRD

Cylindrical Inductive Long-Distance Proximity Sensors

The PRD series cylindrical inductive proximity sensors are available in standard and IO-Link communication models. The sensors feature long sensing distances and excellent noise immunity. Available in various sizes and sensing distances, the high performance cylindrical inductive sensors can be used in diverse applications requiring non-contact detection of metallic objects. The sensors also feature strain relief cables for improved flexural strength and durability.



PRD AT A GLANCE

Main Features
  • Operation indicator (red LED)
  • Communication indicator for IO-Link model (orange, green LED)
  • Protection structure: IP67
  • Strain relief cables: improved flexural strength of cable connecting component (except M8 models)
  • PTFE coating prevents malfunctions caused by welding spatter (spatter-resistant model)

Technical details-

Installation Non-flush
Sensing side diameter Ø30mm
Sensing distance 25mm
Hysteresis(distance) Max. 10% of sensing distance
Standard sensing target 75×75×1mm(iron)
Response frequency 100Hz
Indicator Operation indicator (red LED)
Unit weight (packaged weight) ≈ 150g (≈ 190g)
Power voltage 12 – 24 VDC (ripple P-P: ≤ 10 %), operating voltage: 10 – 30 VDC
Current specification Leakage current: Max. 0.6mA
Control output 2 to 100 mA
Residual voltage Max. 3.5V
Protection circuit Surge protection circuit, output short over current protection circuit, reverse polarity protection circuit
Insulation resistance ≥ 50 MΩ (500 VDC megger)
Dielectric strength 1,500 VAC~ 50/60Hz for 1 minute
Vibration 1.0 mm amplitude at frequency of 10 to 55 Hzin each X, Y, Z direction for 2 hours
Shock 500 m/s² (≈ 50 G) in each X, Y, Z direction for 3 times
Environment_Ambient temperature -25 to 70 ℃, storage: -30 to 80 ℃ (no freezing or condensation)
Environment_Ambient humidity 35 to 95 %RH, storage: 35 to 95 %RH (no freezing or condensation)
Protection structure IP67(IEC standard)
Connection Connector models
Connector type M12 Connector
Material Case/Nut: nickel plated brass (DIA. of sensing side Ø 8 mm connector type case: SUS303), washer: nickel plated iron, sensing side: PBT

※The response frequency is the average value. The standard sensing target is used and the width is set as 2 times of the standard sensing target, 1/2 of the sensing distance for the distance.
※Check the condition of connected device.

Datasheet: PDF
