AUTONICS CR30-15AC

AUTONICS Capacitive Proximity Sensors | CR30-15AC

  • Sensing range (max.): 15 mm
  • Connection type: M12 Connector cable
  • Output function: NC
  • Switching frequency: 20 Hz
  • Installation type: Non Flush



For Price Call: 01329727092
Email: sales@voltecbd.com
Category:
Tags:

Description

AUTONICS Capacitive Proximity Sensors | CR30-15AC

AUTONICS Capacitive Proximity Sensors

AUTONICS Capacitive Proximity Sensors Supplier in Bangladesh

CR

Cylindrical Capacitive Proximity Sensors

The CR series cylindrical capacitive proximity sensors are capable of detecting any material with dielectric different from air. The sensors can detect conductive and non-conductive materials including metal, iron, stone, plastic, water, and grain. The built-in sensitivity adjuster allows easy configuration of detecting distance, making it ideal for application in various environmental settings.



CR AT A GLANCE

Main Features
  • Detect various materials including metal, iron, stone, plastic, water, and grain
  • Built-in sensitivity adjuster for convenient configuration
  • Operation indicator (red LED)
  • Ideal for level detection and position control

Technical details-

Wire type and power AC 2-wire type
100-240VAC~
Sensing side diameter M30
Sensing distance 15mm
Standard sensing target 50×50×1mm(iron)
Response frequency 20Hz
Current specification Leakage current: Max. 2.2mA
Control output Normally Closed
Material Brass(nickel plated)
Protection structure IP65
Environment_Ambient temperature -25 to 70℃, storage: -30 to 80℃
Environment_Ambient humidity 35 to 95% RH, storage: 35 to 95% RH
Hysteresis(distance) Max. 20% of sensing distance
Weight ≈ 200g (≈ 237g)

※The response frequency is the average value. The standard sensing target is used and the width is set as 2 times of the standard sensing target, 1/2 of the sensing distance for the distance.
※The weight includes packaging. The weight in parenthesis is for unit only.
※The temperature or humidity mentioned in Environment indicates a non freezing or condensation.

Datasheet: PDF

More Capacitive proximity sensors :

AUTONICS CR30-15DP, AUTONICS CR18-8AC, AUTONICS CR18-8AO, AUTONICS CR18-8DN2, AUTONICS CR30-15AO, AUTONICS CR30-15DN, AUTONICS CR30-15DN2, AUTONICS CR18-8DN, AUTONICS CR18-8DP
