AUTONICS Inductive Proximity Sensors | PFI25-8DP2
- Sensing range (max.): 8 mm
- Switching output: PNP
- Output function: NC
- Switching frequency: 200 Hz
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
AUTONICS Inductive Proximity Sensors | PFI25-8DP2
AUTONICS Inductive Proximity Sensors
AUTONICS Inductive Proximity Sensors Supplier in Bangladesh
PFI
Rectangular Inductive Flat Type Proximity Sensors
The PFI series flat type inductive proximity sensors feature excellent noise immunity. The flat, compact design with 10 mm height allows the sensors to be installed easily in applications with limited space.
PFI AT A GLANCE
- Flat, compact design (10mm height) allows easy installation in limited spaces
- Operation indicator (red LED)
- Protection structure: IP67
Technical details-
| Wire type and power | DC 3-wire type 12-24VDC |
|---|---|
| Sensing side size | Frame size 25mm |
| Sensing distance | 8mm |
| Standard sensing target | 25×25×1mm(iron) |
| Response frequency | 200Hz |
| Current specification | Current consumption: Max. 10mA |
| Control output | PNP Normally Closed |
| Sensing type | Upper sensing type |
| Material | Poly Phenylene Sulfide |
| Protection structure | IP67(IEC standard) |
| Environment_Ambient temperature | -25 to 70℃, storage: -30 to 80℃ |
| Environment_Ambient humidity | 35 to 95% RH, storage: 35 to 95% RH |
| Hysteresis(distance) | Max. 10% of sensing distance |
| Residual voltage | Max. 1.5V |
| Weight | Approx. 70g |
※The response frequency is the average value. The standard sensing target is used and the width is set as 2 times of the standard sensing target, 1/2 of the sensing distance for the distance.
※The weight includes packaging. The weight in parenthesis is for unit only.
※The temperature or humidity mentioned in Environment indicates a non freezing or condensation.
Datasheet: PDF
