AUTONICS Inductive Proximity Sensors | PRFD30-12DP-V
- Sensing range (max.): 12 mm
- Connection type: Cable type
- Switching frequency: 50 Hz
- Installation type: Flush
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
AUTONICS Inductive Proximity Sensors | PRFD30-12DP-V
AUTONICS Inductive Proximity Sensors
AUTONICS Inductive Proximity Sensors Supplier in Bangladesh
PRFD
Cylindrical Inductive Full-Metal Long-Distance Proximity Sensors
The PRFD series cylindrical proximity sensors are available in standard and IO-Link communication models. The sensors feature long sensing distances and full-metal housing and sensor heads made of stainless steel 303. The robust sensors provide high durability and can be applied in diverse environments including food and beverage manufacturing, chemical, and metalworking industries. The status indicator offers users to quickly identify operation status from various angles.
PRFD AT A GLANCE
- High durability against contact with workpieces or wire brushes (sensor head/housing: stainless steel)
- Reduced risk of malfunction caused by aluminum chips
- 2-color LED indicator for easy status monitoring
- Malfunction identification and predictive maintenance with real-time monitoring (IO-Link models : PRFDCM□-□-IL2)
- Oil resistant cable
- Protection structure
– Cable type, cable connector type: IP66, IP67
– Connector type : IP66, IP67, IP67G, IP68 - PTFE coating prevents malfunctions caused by welding spatter (spatter-resistant PRFDA□ models)
Technical details-
| Installation | Flush |
|---|---|
| Sensing side diameter | Ø30mm |
| Sensing distance | 12mm |
| Hysteresis(distance) | Max. 15% of sensing distance |
| Standard sensing target | 54×54×1mm(iron) |
| Response frequency | 50Hz |
| Indicator | Operation indicator (orange), stable indicator (green), Abnormal detect indicator (cross-flashing green, orange) |
| Unit weight (packaged weight) | ≈ 165 g (≈ 220 g) |
| Power voltage | 10 – 30 VDC (ripple P-P: ≤ 10 %) |
| Current specification | Current consumption: Max. 20mA |
| Control output | Max. 100mA |
| Residual voltage | ≤ 2.5 V |
| Protection circuit | Surge protection circuit, output short over current protection circuit, reverse polarity protection circuit |
| Insulation resistance | ≥ 50 MΩ (500 VDC megger) |
| Dielectric strength | 1,000 VAC~ 50 / 60 Hz for 1 minute (between all terminals and case) |
| Vibration | 1.5 mm amplitude at frequency of 10 to 55Hz in each X, Y, Z direction for 2 hours |
| Shock | 1,000 m/s² (≈ 100 G) in each X, Y, Z direction for 10 times |
| Environment_Ambient temperature | -25 to 70 ℃, storage: -25 to 70 ℃ (no freezing or condensation) |
| Environment_Ambient humidity | 35 to 95 %RH, storage: 35 to 95 %RH (no freezing or condensation) |
| Protection structure | IP66, IP67 (IEC standard) |
| Connection | Cable type |
| Cable Standard/material | Oil resistant cable (dark gray) |
| Material | Case / Nut: stainless steel 303 (SUS303), washer: stainless steel 304 (SUS304), sensing side: stainless steel 303 (SUS303) |
※Use accessories (nut, washer) made of SUS. Or, sensing distance cannot be guaranteed.
※The response frequency is the average value. The standard sensing target is used and the width is set as 2 times of the standard sensing target, 1/2 of the sensing distance for the distance.
※Ambient temp.: UL approved surrounding air temperature 60 ℃
Datasheet: PDF
