AUTONICS PRFAWT30-10DO-IV

AUTONICS Inductive Proximity Sensors | PRFAWT30-10DO-IV

  • Sensing range (max.): 10 mm
  • Connection type: M12 connector
  • Switching frequency: 50 Hz
  • Installation type: Flush



For Price Call: 01329727092
Email: sales@voltecbd.com
Category:
Tags:

Description

AUTONICS Inductive Proximity Sensors | PRFAWT30-10DO-IV

AUTONICS Inductive Proximity Sensors

AUTONICS Inductive Proximity Sensors Supplier in Bangladesh

PRF

Cylindrical Inductive Full-Metal Proximity Sensors

The PRF series cylindrical proximity sensors feature full-metal housing and sensor head made of stainless steel 303. The robust sensors are highly resistant to deformation and corrosion and can be applied in diverse environments including food and beverage manufacturing, chemical, and metalworking industries. The 0.8 mm thick metal sensor head provides high resistance to impact and wear and the 360° ring type operation indicator allows users to quickly identify operation status from various angles.



PRF AT A GLANCE

Main Features
  • High resistance to impact and wear caused by contact with workpieces or wire brushes (sensor head/housing: stainless steel)
  • Reduced risk of malfunction caused by aluminum chips
  • 360° ring type operation indicator (red LED) (except M8 models)
  • Oil resistant cable
  • Protection structure: IP67
  • PTFE coating prevents malfunctions caused by welding spatter (spatter-resistant models)

Technical details-

Installation Flush
Sensing side diameter Ø30mm
Sensing distance 10mm
Hysteresis(distance) Max. 15% of sensing distance
Standard sensing target 54×54×1mm(iron)
Response frequency 50Hz
Indicator Operation indicator (red LED)
Unit weight (packaged weight) ≈ 170 g (≈ 225 g)
Power voltage 12 – 24 VDC (ripple P-P: ≤ 10 %), operating voltage: 10 – 30 VDC
Current specification Leakage current: Max. 0.8mA
Control output 3 to 100 mA
Residual voltage Max. 3.5V
Protection circuit Surge protection circuit, output short over current protection circuit, reverse polarity protection circuit
Insulation resistance ≥ 50 MΩ (500 VDC megger)
Dielectric strength Between the charging part and the case: 1,000 VAC~ 50/60 Hz for 1 minute
Vibration 1.5 mm amplitude at frequency of 10 to 55Hz in each X, Y, Z direction for 2 hours
Shock 1,000 m/s² (≈ 100 G) in each X, Y, Z direction for 10 times
Environment_Ambient temperature -25 to 70 ℃, storage: -25 to 70 ℃ (no freezing or condensation)
Environment_Ambient humidity 35 to 95 %RH, storage: 35 to 95 %RH (no freezing or condensation)
Protection structure IP67(IEC standard)
Connection Cable connector type
Connector type M12 Connector
Cable Standard/material Oil resistant cable (gray): polyvinyl chloride (oil resistant PVC)
Material Case / Nut: stainless steel 303 (SUS303, PTFE coated), washer: stainless steel 304 (SUS304), sensing side: stainless steel 303 (SUS303, PTFE coated)

※Use accessories (nut, washer) made of SUS. Or, sensing distance cannot be guaranteed.
※The response frequency is the average value. The standard sensing target is used and the width is set as 2 times of the standard sensing target, 1/2 of the sensing distance for the distance.
※Ambient temp.: UL approved surrounding air temperature 40 ℃

Datasheet: PDF
