YASKAWA AC Drive L1000A | CIMR-LC4F0009BAA | 3.7 kW
- Rated output current: 9.2 A
- Max. applicable motor power: 3.7 kW
- Input power supply: 400 V
- Max Output Frequency: 200 Hz
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
YASKAWA AC Drive L1000A | CIMR-LC4F0009BAA | 3.7 kW
YASKAWA AC Drive
YASKAWA AC Drive Supplier in Bangladesh
L1000A
Rise to the Top – Yaskawa L1000 lift drives are the solution to technical requirements of today’s elevators. This lift drive controls induction and permanent magnet motors. It is the first choice for new installation, machine room less lifts, but also for modernization. Experience the proven Yaskawa reliability combined with a new level of ride comfort.
- Flexible controller interface
- Brake monitoring
- Operation without motor contactors
- Rescue operation
Technical Details
| Property | Value |
| Input power supply | 400 V |
| Rated output current (HD) | 9.2 A |
| Overload Tolerance (ND) | 120 % for 60 s |
| Overload Tolerance (HD) | 150 % for 60 s |
| Max. applicable motor power (HD) | 3.7 kW |
| Input power phases | 3-phase |
| Motor type | Induction motor, Permanent magnet motor |
| Encoder | ✓ Yes |
| Standards compliance | CE, RoHS, UL, cUL, UKCA |
| Ambient Temperature (Max) | 50 °C |
| Height | 260 mm |
| Width | 140 mm |
| Depth | 164 mm |
| Weight | 3.5 kg |
| Cooling method | Air cooling |
| Enclosure | IP20 |
| Environmental Specifications | Standard |
| Analog Input | 2 |
| Analog Output | 2 |
| Digital Input | 8 |
| Digital Output | 6 |
| Safety Level | SIL2 |
| Performance Level | PL d |
| Torque Control | Not available |
| Motor Thermal Protection | Standard |
| Max Output Frequency | 200 Hz |
Datasheet: PDF
