WAGO 750-504

WAGO 4-channel Digital Output | 750-504

  • Number of digital outputs: 4
  • Switching frequency (max.): 1 kHz
  • Signal type (voltage): 24 VDC
  • Output current per channel: 0.5 A
  • Supply voltage (system): 5 VDC



For Price Call: 01329727092
Email: sales@voltecbd.com
Category:
Tags:

Description

WAGO 4-channel Digital Output | 750-504

WAGO Digital Output

WAGO I/O Systems Supplier in Bangladesh

I/O Systems

For optimal automation both inside and outside the control cabinet: the flexible IP20 and IP67 remote I/O systems for all applications and environments.

Benefits with WAGO’s I/O Systems:

  • Fieldbus-independent: Compatible with all standard fieldbus protocols and ETHERNET standards
  • Wide variety of I/O modules available for nearly every application
  • International and national approvals for worldwide use
  • Extensive range of accessories for marking and connection technology
  • IP20 I/O systems – equipped with CAGE CLAMP® technology for rapid, vibration-proof, maintenance-free connections
  • IP67 I/O system – fully encapsulated and completely shielded for harsh environments



Technical Features:-

Number of digital outputs 4
Total number of channels (module) 4
Signal type Digital
Signal type (voltage) 24 VDC
Actuator connection 2 x (2-wire, 3-wire); A suitable field side connection module (e.g., 750-614) must also be used to connect other actuators.
Output characteristic high-side switching
Output current per channel 0.5A
Output current short-circuit-protected
Load type Resistive, inductive, lamp load
Switching frequency (max.) 1 kHz
Inductive load switch-off energy dissipation (max.) 0.3J
Output data width (internal) max. 4Bit
Supply voltage (system) 5 VDC; via data contacts
Current consumption (system supply) 10mA
Supply voltage (field) 24 VDC (-25 … +30 %); via power jumper contacts (power supply via blade contact; transmission (field side supply voltage only) via spring contact)
Current consumption, field supply (module with no external load) 30mA
Isolation 500 V system/field
Indicators LED (A-D) green: Status DO 1 … DO 4
Number of incoming power jumper contacts 2
Number of outgoing power jumper contacts 2
Current carrying capacity (power jumper contacts) 10A



Datasheet: PDF
