WAGO 750-466

WAGO 2-channel Analog Input | 750-466

  • Number of analog inputs: 2
  • Signal type (current): 4 – 20 mADC
  • Input voltage (max.): 10 V
  • Supply voltage (field): 24 VDC (-25 … +30 %)
  • Input resistance (max.): 220 Ω



For Price Call: 01329727092
Email: sales@voltecbd.com
Category:
Tags:

Description

WAGO 2-channel analog input | 750-466

WAGO Analog Input

WAGO Analog input Supplier in Bangladesh

I/O Systems

For optimal automation both inside and outside the control cabinet: the flexible IP20 and IP67 remote I/O systems for all applications and environments.

Benefits with WAGO’s I/O Systems:

  • Fieldbus-independent: Compatible with all standard fieldbus protocols and ETHERNET standards
  • Wide variety of I/O modules available for nearly every application
  • International and national approvals for worldwide use
  • Extensive range of accessories for marking and connection technology
  • IP20 I/O systems – equipped with CAGE CLAMP® technology for rapid, vibration-proof, maintenance-free connections
  • IP67 I/O system – fully encapsulated and completely shielded for harsh environments



Technical Features:-

Number of analog inputs 2
Total number of channels (module) 2
Signal type Current
Signal type (current) 4 … 20 mADC
Sensor connection 2 x (2-wire, 3-wire)
Input voltage (max.) 10 V
Signal characteristics Single-ended
Resolution [bit] 12Bit
Input resistance (max.) 220Ω
Data width 2 x 16-bit data; 2 x 8-bit control/status (optional)
Conversion time (typ.) 2ms
Measurement error (reference temperature) 25°C
Measurement error, deviation (max.) from the upper-range value 0.2%
Temperature error (max.) of the upper-range value 0.01%/K
Supply voltage (system) 5 VDC; via data contacts
Current consumption (system supply) 75mA
Supply voltage (field) 24 VDC (-25 … +30 %); via power jumper contacts (power supply via blade contact; transmission (field side supply voltage only) via spring contact)
Isolation 500 V system/field
Indicators LED (A, C) green: Function AI 1, AI 2; LED (B, D) red: Error AI 1, AI 2
Number of incoming power jumper contacts 2
Number of outgoing power jumper contacts 2



Datasheet: PDF
