SICK WTM10L-241612D0A00ZVZZZZZZZZZ1

SICK Photoelectric Sensors WTM10L-241612D0A00ZVZZZZZZZZZ1 | Part no: 1133545

  • Functional principle: Photoelectric proximity sensor
  • Sensing range: 25 mm – 400 mm
  • Connection type: Male connector M12, 4-pin
  • Output Type: PNP/NPN, Individually adjustable
  • Switching frequency: 30 – 275 Hz
  • Switching mode: Light/dark switching



For Price Call: 01329727092
Email: sales@voltecbd.com
Category:
Tags:

Description

SICK Photoelectric Sensors WTM10L-241612D0A00ZVZZZZZZZZZ1 | Part no: 1133545

SICK Photoelectric Sensors

SICK Photoelectric Sensors Supplier in Bangladesh

W10

Easy to install. Easy to operate. The one photoelectric proximity sensor for all applications.

The W10 photoelectric proximity sensor’s ease of use, sturdy design and performance make it ideal for precise object detection in demanding environments. The touchscreen display is intuitive to use, allowing parameters to be set quickly. Situation-dependent teach-ins allow convenient sensor adaptation to individual applications. The fact that various MultiMode functions and configurations, such as foreground and background suppression, are combined in a single sensor allows success in a wide range of applications.



W10 AT A GLANCE

Benefits
  • Ensure confidence with an easy-to-use, end-to-end sensor experience
  • Reliable, repeatable detection raises efficiency in many applications
  • Convenient product selection by driving the elimination of selection
  • Ideally suited even to harsh and challenging application environments
  • Universally applicable
  • Quick installation and commissioning
  • Optional security – avoid costly down time and reconfiguration
Features
  • The world’s first photoelectric sensor with touchscreen display-enabled sensor with refined user-interface allowing simple operation
  • High performance thanks to a precise laser triangulation system with line scanning
  • Buy one, manage one, inventory one, train one, troubleshoot one, replace one
  • Sturdy design with 316L stainless steel housing and IP69k protection rating
  • MultiMode functions such as speed, standard, and precision mode, foreground and background suppression, and teach options
  • Standardized mounting, pre-configured settings and multiple teach-in options for simple sensor integration
  • Button-free interface with lockout ability

Technical details-

Features

Functional principle Photoelectric proximity sensor
Functional principle detail Background suppression, Foreground suppression, MultiMode
MultiMode Background suppression

Foreground suppression

Single value teach-in

Two Value Teach-in

Manual teach-in

ApplicationSelect (Mode 1 – Speed, Mode 2 – Standard, Mode 3 – Precision)

Measurement
Sensing range
Sensing range min. 25 mm (Mode 1 – Speed)
25 mm (Mode 2 – Standard)
25 mm (Mode 3 – Precision)
Sensing range max. 220 mm (Mode 1 – Speed)
300 mm (Mode 2 – Standard)
400 mm (Mode 3 – Precision)
Adjustable switching threshold for background suppression 25 mm … 220 mm (Mode 1 – Speed)
25 mm … 300 mm (Mode 2 – Standard)
25 mm … 400 mm (Mode 3 – Precision)
Reference object Object with 90% remission factor (complies with standard white according to DIN 5033)
Minimum distance between set sensing range and background (black 6% / white 90%) 2 mm, at a distance of 150 mm (Mode 1 – Speed)
4 mm, At 210 mm distance (Mode 2 – Standard)
10 mm, at a distance of 300 mm (Mode 3 – Precision)
Recommended sensing range for the best performance 50 mm … 150 mm (Mode 1 – Speed)
50 mm … 210 mm (Mode 2 – Standard)
50 mm … 300 mm (Mode 3 – Precision)
Distance value
Measuring range 25 mm … 400 mm
Repeatability < 0.5 % 1) 2) 3)
Accuracy < 3 % 1)
Distance value output Via IO-Link + display
Resolution 1 mm
Emitted beam
Light source Laser
Type of light Visible red light
Shape of light spot Point-shaped
Light spot size (distance) Ø 0.2 mm (150 mm)
Maximum dispersion of the emitted beam around the standardized transmission axis (squint angle) < +/- 1.0° (at TU = +23 °C)
Key laser figures
Normative reference IEC 60825-1 / CDRH 21 CFR 1040.10 & 1040.11, EN 60825-1:2014, IEC 60825-1:2014 (except for tolerances according to Laser Notice No. 56 dated May 8, 2019)
Laser class 1 4)
Wave length 655 nm
Pulse duration 4 µs
Maximum pulse power < 2.5 mW
Average service life 50,000 h at TU = +25 °C
Smallest detectable object (MDO) typ.
0.2 mm, at a distance of 150 mm
Object with 90% remission factor (complies with standard white according to DIN 5033)
Adjustment
Touch display For setting the sensing range and configuring the sensor parameters
IO-Link For configuring the sensor parameters and Smart Task functions
Display
Display Display of mode, display of output states, display of the distance value, display of the set value
LED green Operating indicator
Static on: power on
Flashing: IO-Link mode
LED yellow Status of received light beam
Static on: object present
Static off: object not present
Special features MultiMode
Special applications Detecting small objects, Detection of objects moving at high speeds, Detecting flat objects, Detecting uneven, shiny objects, Detection of poorly remitting and tilted objects

1) 90% remission factor.

2) Equivalent to 1 σ.

3) Observe min. warm-up time of 15 minutes.

4) Do not intentionally look into the laser beam. Never point the laser beam at people’s eyes.

Mechanics

Housing Rectangular
Dimensions (W x H x D) 18 mm x 57 mm x 42.2 mm
Connection Male connector M12, 4-pin
Material
Housing Metal, Stainless steel V4A (1.4404, 316L)
Front screen Plastic, PMMA
Display cover Plastic, PMMA
LED Plastic, ABS
Male connector Metal, Stainless steel V4A (1.4404, 316L)
Weight Approx. 100 g
Maximum tightening torque of the fixing screws 0.56 Nm





Datasheet: PDF
