SICK Photoelectric Sensors GTB10-P4001S23 | Part no: 1122172
- Functional principle: Photoelectric proximity sensor
- Sensing range (max.): 20 mm – 950 mm
- Connection type: Male connector M12, 4-pin
- Output Type: PNP
- Switching frequency: 500 Hz
- Switching mode: Dark switching
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
SICK Photoelectric Sensors GTB10-P4001S23 | Part no: 1122172
SICK Photoelectric Sensors
SICK Photoelectric Sensors Supplier in Bangladesh
G10
Powerful detection, smart installation – down to the last detail
The G10 product family is characterized by optimum detection performance wherever space is at a premium. It supports numerous different options for optics, electronics, principles of operation, power supplies, and switching outputs. Combined with an extensive range of accessories, these sensors are able to support a wide variety of applications. The patented Q-Lock assembly system for the G10 reduces the time required to install and align the sensor with an assembly rod to just a few seconds, making this the ideal product for logistics applications. Summary: The G10 product family provides quick and flexible sensor installation, ensures error-free operation, and keeps costs under control.
G10 AT A GLANCE
- Long sensing ranges for maximum operating reserves
- Efficient installation: The G10 and the Q-Lock assembly system save valuable hours when mounting and commissioning multiple sensors
- A single sensor family for all industrial and commercial fields of application
- Universal DC or AC/DC power supply for even greater application flexibility
- Highly reliable and durable despite optical interference or mechanical loads
- Wide range of accessories simplifies sensor integration: aids for assembly, connecting cables, and reflectors
- Long sensing ranges: 1,200 mm with background suppression; 15 m on PL80A reflector
- PinPoint LED with bright and precise light spot
- Small housing design
- 10 … 30 VDC or 24 … 240 VAC/VDC power supply with PNP/NPN or relay output
- Rugged sensor housing with metal-reinforced holes for assembly
- Q-Lock assembly system for mounting the sensor within a few seconds
Technical details-
Features
| Functional principle | Photoelectric proximity sensor |
| Functional principle detail | Background suppression |
| Dimensions (W x H x D) | 20 mm x 50 mm x 39 mm |
| Housing design (light emission) | Rectangular |
| Sensing range max. | 20 mm … 950 mm 1) |
| Type of light | Visible red light |
| Light source | PinPoint LED 2) |
| Light spot size (distance) | Ø 4.5 mm (300 mm) |
| Wave length | 625 nm |
| Adjustment | Potentiometer, 5 turns |
| Special features | High functional reliability on foil-wrapped objects
Sensing range preset, 400 mm / white (90 % Remission) With glue on the potentiometer (when apply small torque on potentiometer knob, sensing range still can be adjusted) |
1) Object with 90% remission (based on standard white, DIN 5033).
2) Average service life: 100,000 h at TU = +25 °C.
Mechanics/Electronics
| Supply voltage UB | 10 V DC … 30 V DC 1) |
| Ripple | < 5 Vpp 2) |
| Current consumption | 20 mA |
| Switching output | PNP |
| Switching mode | Dark switching |
| Output current Imax. | ≤ 100 mA |
| Response time | ≤ 1 ms 3) |
| Switching frequency | 500 Hz 4) |
| Connection type | Male connector M12, 4-pin |
| Circuit protection | A 5)
B 6) C 7) D 8) |
| Protection class | III |
| Weight | 53.8 g |
| Special device | ✔ |
| Housing material | Plastic, ABS/PMMA |
| Enclosure rating | IP67 |
| Electromagnetic compatibility (EMC) | EN 60947-5-2 |
| Ambient operating temperature | –30 °C … +60 °C |
| Ambient temperature, storage | –40 °C … +70 °C |
| UL File No. | NRKH.E348498 & NRKH7.E348498 |
| More standards | UL325 9) |
1) Limit values when operated in short-circuit protected network: max. 8 A.
2) May not fall below or exceed UV tolerances.
3) Signal transit time with resistive load.
4) With light/dark ratio 1:1.
5) A = VS connections reverse-polarity protected.
6) B = inputs and output reverse-polarity protected.
7) C = interference suppression.
8) D = outputs overcurrent and short-circuit protected.
9) Complies with the UL325 standard when used with sturdy protection hood (e.g. BEF-G10WSG, 2071960).
Datasheet: PDF
