SICK Photoelectric Sensors GL10-R9812 | Part no: 1076130
- Functional principle: Photoelectric retro-reflective sensor
- Sensing range (max.): 0.08 m – 15 m
- Connection type: Cable, 5-wire, 5 m
- Switching frequency: 20 Hz
- Switching mode: Light/dark switching
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
SICK Photoelectric Sensors GL10-R9812 | Part no: 1076130
SICK Photoelectric Sensors
SICK Photoelectric Sensors Supplier in Bangladesh
G10
Powerful detection, smart installation – down to the last detail
The G10 product family is characterized by optimum detection performance wherever space is at a premium. It supports numerous different options for optics, electronics, principles of operation, power supplies, and switching outputs. Combined with an extensive range of accessories, these sensors are able to support a wide variety of applications. The patented Q-Lock assembly system for the G10 reduces the time required to install and align the sensor with an assembly rod to just a few seconds, making this the ideal product for logistics applications. Summary: The G10 product family provides quick and flexible sensor installation, ensures error-free operation, and keeps costs under control.
G10 AT A GLANCE
- Long sensing ranges for maximum operating reserves
- Efficient installation: The G10 and the Q-Lock assembly system save valuable hours when mounting and commissioning multiple sensors
- A single sensor family for all industrial and commercial fields of application
- Universal DC or AC/DC power supply for even greater application flexibility
- Highly reliable and durable despite optical interference or mechanical loads
- Wide range of accessories simplifies sensor integration: aids for assembly, connecting cables, and reflectors
- Long sensing ranges: 1,200 mm with background suppression; 15 m on PL80A reflector
- PinPoint LED with bright and precise light spot
- Small housing design
- 10 … 30 VDC or 24 … 240 VAC/VDC power supply with PNP/NPN or relay output
- Rugged sensor housing with metal-reinforced holes for assembly
- Q-Lock assembly system for mounting the sensor within a few seconds
Technical details-
Features
| Functional principle | Photoelectric retro-reflective sensor |
| Functional principle detail | With minimum distance to reflector (dual lens system) |
| Dimensions (W x H x D) | 20 mm x 50 mm x 51.5 mm |
| Housing design (light emission) | Rectangular |
| Sensing range max. | 0.08 m … 15 m 1)
0.08 m … 12 m 2) |
| Sensing range | 0.15 m … 12 m 1)
0.15 m … 10 m 2) |
| Type of light | Visible red light |
| Light source | PinPoint LED 3) |
| Light spot size (distance) | Ø 58 mm (5 m) |
| Wave length | 625 nm |
| Adjustment | Potentiometer, 270° |
1) Reflector PL80A.
2) Reflector P250.
3) Average service life: 100,000 h at TU = +25 °C.
Mechanics/Electronics
| Supply voltage Ue | 24 V AC/DC … 240 V AC/DC 1) |
| Ripple | < 10 % |
| Power consumption | ≤ 2.5 VA |
| Switching output | Relay, SPDT, electrically isolated 2) |
| Switching mode | Light/dark switching 2) |
| Switching load max. (current/voltage) | 0.11 A (250 V DC)
3 A (30 V DC) 3 A (250 V AC) |
| Response time | ≤ 10 ms |
| Switching frequency | 20 Hz 3) |
| Connection type | Cable, 5-wire, 5 m 4) |
| Cable material | Plastic, PVC |
| Conductor cross section | 0.25 mm² |
| Circuit protection | C 5) |
| Protection class | II 6) |
| Weight | 115 g |
| Polarizing filter | ✔ |
| Interference emission | EN 61000-6-3 (2011-09) 7) |
| Housing material | Plastic, ABS/PMMA |
| Enclosure rating | IP67 |
| Relay switching cycles min. | 100.000 cycles (3 A) |
| Items supplied | Mounting bracket BEF-G10UC01, Reflector P250 |
| Usage category | DC-13 (according to EN 60947-1)
AC-15 (according to EN 60947-1) |
| Electromagnetic compatibility (EMC) | EN 60947-5-2 EN 61000-6-3 (2011-09) |
| Ambient operating temperature | –30 °C … +60 °C 8) |
| Ambient temperature, storage | –40 °C … +70 °C |
| UL File No. | NRKH.E348498 & NRKH7.E348498 |
| More standards | UL325 9) |
1) +- 10 %.
2) Provide suitable spark suppression for inductive or capacitive loads.
3) With light/dark ratio 1:1.
4) Do not bend below 0 °C.
5) C = interference suppression.
6) Reference voltage: 250 V AC.
7) In the case of a DC supply (ref. to EN 61000-6-3) the length of cable between the supply source and the sensor must be < 30 m.
8) UL: 0 °C … +50 °C.
9) Complies with the UL325 standard when used with sturdy protection hood (e.g. BEF-G10WSG, 2071960).
Datasheet: PDF
