Sick IQ08-04NPOKW2S

SICK Inductive Proximity Sensors IQ08-04NPOKW2S | Part no: 1055499

  • Sensing range (max.): 4 mm
  • Digital output type: PNP
  • Output function: NC
  • Switching frequency: 2,000 Hz
  • Installation type: Non-flush



For Price Call: 01329727092
Email: sales@voltecbd.com
Category:
Tags:

Description

SICK Inductive Proximity Sensors IQ08-04NPOKW2S | Part no: 1055499

SICK Inductive Proximity Sensors

SICK Inductive Proximity Sensor Supplier in Bangladesh

IQY

Small cubic inductive standard sensors for industrial use

With slim dimensions of just 5 mm x 5 mm or 8 mm x 8 mm, the IQY sensors offer up to 4 mm in sensing range, thereby providing the best performance while taking up the least possible space. Integration into linear units or confined installation spaces is no problem. State-of-the-art SICK-ASIC technology, innovative hotmelt molding and an output state display that is visible from all angles makes a simple solution for modern handling and automation tasks, ensuring the highest levels of production reliability. No matter whether in VISTAL® or metal housing, the sensors of the IQV product family rise to every challenge with ease.

IQY AT A GLANCE
Benefits
  • Easy integration in space-critical applications
  • Reliable detection of fast handling and mounting processes
  • Quick and easy mounting
  • Thin housing provides a high degree of design freedom
Features
  • Types: 5 mm x 5 mm x 25 mm or 8 mm x 8 mm x 40 mm
  • Extended sensing ranges: 0.8 mm to 4 mm
  • Electrical configuration: DC 3-wire
  • Enclosure rating: IP67 or IP68
  • Temperature range: –25 °C to +75 °C
  • Tough VISTAL™ housing
  • Thin version with 270° output state display



Technical details-

Features

Housing Rectangular
Dimensions (W x H x D) 8 mm x 40 mm x 8 mm
Sensing range Sn 4 mm
Safe sensing range Sa 3.24 mm
Installation type Non-flush
Switching frequency 2,000 Hz
Connection type Cable, 3-wire, 2 m
Switching output PNP
Switching output detail PNP
Output function NC
Electrical wiring DC 3-wire
Enclosure rating IP67 1)

IP68

1) According to EN 60529.

Mechanics & Electronics

Supply voltage 10 V DC … 30 V DC
Ripple ≤ 10 % 1)
Voltage drop ≤ 2 V 2)
Time delay before availability ≤ 100 ms
Hysteresis 5 % … 15 %
Reproducibility ≤ 2 % 3)

4)
Temperature drift (of Sr) ± 10 %
EMC According to EN 60947-5-2
Continuous current Ia ≤ 200 mA
No load current 10 mA
Cable material PVC
Conductor size 0.14 mm²
Cable diameter Ø 2.9 mm
Short-circuit protection ✔
Power-up pulse protection ✔
Shock and vibration resistance 30 g, 11 ms / 10 … 55 Hz, 1 mm
Ambient operating temperature –25 °C … +75 °C
Housing material Plastic, VISTAL®
Sensing face material Plastic, VISTAL®
Tightening torque, max. ≤ 1.5 Nm
UL File No. NRKH.E348498

1) Of VS.

2) At Ia max.

3) Supply voltage UB and constant ambient temperature Ta.

4) Of Sr.

Datasheet: PDF
