Sick IQ80-60NPP-KK0

SICK Inductive Proximity Sensors IQ80-60NPP-KK0 | Part no: 7900227

  • Sensing range (max.): 60 mm
  • Connection type: Terminal connection with M20 gland
  • Switching output: PNP
  • Output function: NC or NO
  • Switching frequency: 100 Hz
  • Installation type: Non-flush



For Price Call: 01329727092
Email: sales@voltecbd.com
Category:
Tags:

Description

SICK Inductive Proximity Sensors IQ80-60NPP-KK0 | Part no: 7900227

SICK Inductive Proximity Sensors

SICK Inductive Proximity Sensors Supplier in Bangladesh

IQL

Large cubic inductive sensors for industrial use

With an adjustable sensing range of up to 60 mm, the sensors of the IQL product family offer a high degree of detection ease. Thanks to the freely configurable N/O and N/C output function, they also reduce costs in new and existing applications. Due to installation from above and the extended sensing range, the IQL sensors are optimally suited for recessed floor mounting, as is often found in the automotive industry or storage and conveyor technology. The IQL is also the number one choice when it comes to other applications.



IQL AT A GLANCE
Benefits
  • Increase in machine availability
  • Reduced mechanical damage
  • Longer service life for reduced costs
  • Quick and safe installation
Features
  • Type: 80 mm x 80 mm
  • Longer sensing ranges: 50 mm to 60 mm
  • Electrical configuration: DC 3-/4-wire, or AC/DC 2-wire
  • Enclosure rating IP65 or IP67
  • Temperature range: –25 °C to +80 °C
  • Plastic housing
  • Programmable N/O or N/C function
  • Sensing range setting via potentiometer

Technical details-

Features

Housing Rectangular
Housing Standard design
Dimensions (W x H x D) 80 mm x 105 mm x 40 mm
Sensing range Sn 60 mm
Safe sensing range Sa 48.6 mm
Installation type Non-flush
Switching frequency 100 Hz
Connection type Terminal connection with M20 gland
Switching output PNP
Switching output detail PNP
Output function NC or NO
Output characteristic Wire configurable
Electrical wiring DC 3-wire
Enclosure rating IP65 1)

1) According to EN 60529.

Mechanics & Electronics

Supply voltage 10 V DC … 36 V DC
Voltage drop ≤ 2.5 V 1)
Hysteresis 1 % … 15 %
Temperature drift (of Sr) ± 10 %
EMC According to EN 60947-5-2
Continuous current Ia ≤ 250 mA
Off-state current ≤ 0.5 mA
Cable gland clamping area M20 1.5
Wire size ≤ 2.5 mm²
Short-circuit protection ✔
Power-up pulse protection ✔
Shock and vibration resistance 30 g, 11 ms / 10 … 55 Hz, 1 mm
Ambient operating temperature –25 °C … +80 °C
Housing material Plastic, PPE
Sensing face material Plastic, PPE

1) With Ia max and Ub 24 V.

Datasheet: PDF

More Inductive proximity sensors :

SICK IQ80-50BPP-KC0 (6026473), SICK IQ80-60NUP-KK0 (7902138)
