SICK Inductive Proximity Sensors IQ80-50BPP-KC0 | Part no: 6026473
- Sensing range (max.): 50 mm
- Connection type: Male connector M12, 4-pin
- Switching output: PNP
- Output function: Complementary
- Switching frequency: 70 Hz
- Installation type: Flush/Non-flush/Over flush
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
SICK Inductive Proximity Sensors IQ80-50BPP-KC0 | Part no: 6026473
SICK Inductive Proximity Sensors
SICK Inductive Proximity Sensors Supplier in Bangladesh
IQL
Large cubic inductive sensors for industrial use
With an adjustable sensing range of up to 60 mm, the sensors of the IQL product family offer a high degree of detection ease. Thanks to the freely configurable N/O and N/C output function, they also reduce costs in new and existing applications. Due to installation from above and the extended sensing range, the IQL sensors are optimally suited for recessed floor mounting, as is often found in the automotive industry or storage and conveyor technology. The IQL is also the number one choice when it comes to other applications.
- Increase in machine availability
- Reduced mechanical damage
- Longer service life for reduced costs
- Quick and safe installation
- Type: 80 mm x 80 mm
- Longer sensing ranges: 50 mm to 60 mm
- Electrical configuration: DC 3-/4-wire, or AC/DC 2-wire
- Enclosure rating IP65 or IP67
- Temperature range: –25 °C to +80 °C
- Plastic housing
- Programmable N/O or N/C function
- Sensing range setting via potentiometer
Technical details-
Features
| Housing | Rectangular |
| Housing | Standard design |
| Dimensions (W x H x D) | 80 mm x 92 mm x 40 mm |
| Sensing range Sn | 50 mm |
| Safe sensing range Sa | 40.5 mm |
| Installation type | Flush
Non-flush Overflush |
| Switching frequency | 70 Hz |
| Connection type | Male connector M12, 4-pin |
| Switching output | PNP |
| Switching output detail | PNP |
| Output function | Complementary |
| Electrical wiring | DC 4-wire |
| Enclosure rating | IP67 1) |
1) According to EN 60529.
Mechanics & Electronics
| Supply voltage | 10 V DC … 36 V DC |
| Voltage drop | ≤ 2.5 V 1) |
| Hysteresis | 3 % … 20 % |
| Temperature drift (of Sr) | ± 15 % |
| EMC | According to EN 60947-5-2 |
| Continuous current Ia | ≤ 250 mA |
| Short-circuit protection | ✔ |
| Shock and vibration resistance | 30 g, 11 ms / 10 … 55 Hz, 1 mm |
| Ambient operating temperature | –25 °C … +70 °C |
| Housing material | Zinc diecast, GD Zn |
| Sensing face material | Plastic, PPE |
1) With Ia max and Ub 24 V.
Datasheet: PDF
