SICK Inductive Proximity Sensors IMR30-30NPSTC0S | Part no: 6069280
- Sensing range (max.): 30 mm
- Connection type: Male connector M12, 4-pin
- Switching output: PNP
- Output function: NO
- Switching frequency: 1000 Hz
- Installation type: Non-flush
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
SICK Inductive Proximity Sensors IMR30-30NPSTC0S | Part no: 6069280
SICK Inductive Proximity Sensors
SICK Inductive Proximity Sensor Supplier in Bangladesh
IMR
Inductive reduction factor 1 sensors for welding applications
The IMR inductive proximity sensors are not the least bothered by magnetic interference fields or weld spatter, such as arise in resistance welding applications. IMR sensors are made without a ferrite core, which makes them magnetic field resistant, and also have a very high electromagnetic compatibility. Thanks to the rugged non-stick coating made from PTFE, these sensors provide very good protection against flying sparks and slag deposits, thereby guaranteeing a high operational safety. Since IMR sensors operate on the reduction factor 1 principle, they can detect all metals within the same sensing range. The very high sensing ranges of up to 75 mm help reduce mechanical damage to the sensors and therefore sensor failures, and increase plant availability.
- Switching errors due to electromagnetic fields are precluded
- Long service life, even for welding applications with stringent requirements, thanks to the special PTFE coating
- Extra large sensing range for all metals, e.g. Aluminum or stainless steel, reduces mechanical damage to the sensors and therefore sensor failures, and increases machine availability
- Simple and reliable detection of objects made from different metals
- Reliable even under harsh ambient conditions thanks to the extended temperature range and an IP68 enclosure rating
- Cylindrical design with high switching frequencies for fast automation processes
- Types: M8 to M30, 40 x 40 mm and 80 x 80 mm
- Increased sensing range: up to 75 mm
- Electrical configuration: DC 3- and 4-conductor
- Enclosure rating: IP68
- Temperature range: –30° C to +85° C
- PTFE coating for cylindrical thread designs
- Reduction factor 1 for all metals
Technical details-
Features
| Housing | Metric |
| Housing | Standard design |
| Thread size | M30 x 1.5 |
| Diameter | Ø 30 mm |
| Sensing range Sn | 30 mm |
| Safe sensing range Sa | 24.3 mm |
| Installation type | Non-flush |
| Switching frequency | 1,000 Hz |
| Connection type | Male connector M12, 4-pin |
| Switching output | PNP |
| Switching output detail | PNP |
| Output function | NO |
| Electrical wiring | DC 3-wire |
| Enclosure rating | IP68 |
| Special features | Reduction factor 1, Magnetic-field-resistant |
| Special applications | Welding range, Difficult application conditions |
| Items supplied | Mounting nut, brass, PTFE coating (2x)
Washer, brass, PTFE coating, with locking teeth (2x) |
Mechanics & Electronics
| Supply voltage | 10 V DC … 30 V DC |
| Ripple | ≤ 10 % |
| Voltage drop | ≤ 1.8 V 1) |
| Hysteresis | 3 % … 15 % |
| Reproducibility | ≤ 2 % 2)
3) |
| Temperature drift (of Sr) | ≤ ± 10 % ≤ ± 15 % 4) |
| Continuous current Ia | ≤ 200 mA |
| No load current | ≤ 15 mA |
| Off-state current | ≤ 0.1 mA |
| Short-circuit protection | ✔ |
| Magnetic field strength | ≤ 100 mT |
| Shock and vibration resistance | 30 g, 11 ms / 10 … 55 Hz, 1 mm |
| Ambient operating temperature | –30 °C … +85 °C |
| Housing material | PTFE coating, brass |
| Sensing face material | Plastic, PTFE coating |
| Housing length | 62 mm |
| Thread length | 31 mm |
| Tightening torque, max. | Typ. 75 Nm |
| Protection class | II 5) |
| UL File No. | E191603 |
1) At Ia max.
2) Supply voltage UB and constant ambient temperature Ta.
3) Of Sr.
4) –25 °C … +70 °C.
5) Reference voltage: 50 V DC.
Datasheet: PDF
