Sick IM30-10BUS-ZU0

SICK Inductive Proximity Sensors IM30-10BUS-ZU0 | Part no: 7902126

  • Sensing range (max.): 10 mm
  • Connection type: Cable, 2-wire, 2 m
  • Output function: NO
  • Switching frequency: 25 Hz (AC), 50 Hz (DC)
  • Installation type: Flush



For Price Call: 01329727092
Email: sales@voltecbd.com
Category:
Tags:

Description

SICK Inductive Proximity Sensors IM30-10BUS-ZU0 | Part no: 7902126

SICK Inductive Proximity Sensors

SICK Inductive Proximity Sensor Supplier in Bangladesh

IMO

Inductive sensors with AC-DC or AC output stage for industrial use

SICK’s inductive sensors offer precise detection, less downtime, and a long service life. The IMO inductive sensors pack high technology into the smallest of spaces. The integrated ASIC chip enables digital adjustment after the end of the manufacturing process. The saving of values in the ASIC ensures highly precise switching points and very high repeatability of values – for any number of production runs. IMO sensors are completely encapsulated with hot melt technology, which increases these sensors’ life under shock and vibration. The customer benefits from high positioning accuracy in the machine and long-term sensor reliability.



IMO AT A GLANCE
Benefits
  • Highly flexible choice of supply voltage
  • High machine availability thanks to rugged design
  • Reduced machine downtimes thanks to a longer sensor service life
  • High positioning accuracy thanks to precise switching behavior
  • Highly cost-efficient thanks to low purchase costs
Features
  • Types: M12 to M30
  • Simple sensing ranges: 2 to 15 mm
  • Electrical configuration: AC 2-wire, AC/DC 2-wire
  • Enclosure rating: IP67
  • Temperature range: –25 °C to 75 °C
  • Nickel-plated brass housing; plastic sensing face

Technical details-

Features

Housing Metric
Housing Standard design
Thread size M30 x 1.5
Diameter Ø 30 mm
Sensing range Sn 10 mm
Safe sensing range Sa 8.1 mm
Installation type Flush
Switching frequency 25 Hz 1)

50 Hz 2)
Connection type Cable, 2-wire, 2 m
Output function NO
Electrical wiring AC/DC 2-wire
Enclosure rating IP67 3)
Items supplied Mounting nut, brass, nickel-plated (2x)

1) AC.

2) DC.

3) According to EN 60529.

Mechanics & Electronics

Supply voltage 20 V AC/DC … 250 V AC/DC
Voltage drop ≤ 6.5 V AC, ≤ 6 V DC
Time delay before availability ≤ 8 ms
Hysteresis 1 % … 15 %
Reproducibility ≤ 10 % 1)

2)

3)
Temperature drift (of Sr) ± 10 %
EMC According to EN 60947-5-2

As per EN 55011, class B
Continuous current Ia ≤ 350 mA 4)

≤ 250 mA 5)

≤ 100 mA 6)
Off-state current ≤ 2.5 mA (AC 250 V)

≤ 1.3 mA (AC 110 V)

≤ 0.8 mA (DC 24 V)
Minimum load current ≥ 5 mA
Short-time withstand current 2.2 A 7)
Cable material PUR/PVC
Conductor size 0.5 mm²
Short-circuit protection  8)
Power-up pulse protection ✔
Shock and vibration resistance 30 g, 11 ms / 10 … 55 Hz, 1 mm
Ambient operating temperature –25 °C … +70 °C
Housing material Brass, nickel-plated
Sensing face material Plastic, PBT
Housing length 81 mm
Thread length 59 mm
Tightening torque, max. ≤ 50 Nm
Protection class II
Rated insulation voltage Ui 250 V AC
Usage category AC-140 9)

DC-13 10)
Contamination rating 3
Rated impulse withstand voltage 4 kV

1) Supply voltage UB and constant ambient temperature Ta.

2) Of Sr.

3) Repeatability (Ta not constant).

4) AC (+50 °C).

5) AC (+80 °C).

6) DC.

7) 20 ms / 0.5 Hz.

8) Miniature fuse to IEC 60217-2 Sheet 1, ≤ 2 A (quick-blow).

9) Control of small electromagnetic loads with holding currents < 200 mA.

10) Control of solenoids.

Datasheet: PDF
