SICK IMF08-04NPONC0S

SICK Inductive Proximity Sensor IMF08-04NPONC0S | 1076751

  • Diameter: Ø 8mm
  • Sensing Range Sn : 4mm
  • Switching Output: PNP/NC
  • Installation Type: Non-flush
Category:
Tags:

Description

SICK Inductive Proximity Sensor IMF08-04NPONC0S | 1076751

Inductive Proximity Sensor Part No: 1076751

Inductive standard sensors for economical use in industrial environments

SICK’s inductive sensors offer precise detection, less downtime and a long service life. The inductive IME sensors pack high technology into the smallest of spaces. The integrated ASIC chip enables digital adjustment after the end of the manufacturing process. The saving of values in the ASIC ensures highly precise switching points and very high repeatability of values – for any number of production runs. IM sensors are completely encapsulated with hotmelt molding, which greatly increases shock and vibration resistance. The customer benefits from high positioning accuracy in the machine and long-term reliability.

IMF Inductive sensors for hygienic and wet zones

The IMF inductive proximity sensor is the new standard for reliability in the food industry. With its extended sensing ranges, made highly precise thanks to the use of SICK ASIC technology, the IMF ensures reliable, stable processes. What’s more, its wide-ranging specification limits allow the IMF to be used in all areas of food production: a huge benefit when it comes to product selection and warehousing. The optical adjustment indicator saves time during commissioning and helps cut down on errors. Communication via IO-Link is also possible, creating more flexibility and adding more functions for automation applications. With an extensive standard product portfolio available, even special devices can be put into action quickly and easily.

Technical details

Features

Housing Metric
Housing Standard design
Thread size M8 x 1
Diameter Ø 8 mm
Sensing range Sn 4 mm
Safe sensing range Sa 3.24 mm
Installation type Non-flush
Switching frequency 4,000 Hz
Connection type Male connector M12, 4-pin 1)
Switching output PNP
Switching output detail PNP
Output function NC
Electrical wiring DC 3-wire
Enclosure rating IP68 2)

IP69K 3)
Special features Resistant to cleaning agents, Visual adjustment indicator, Temperature resistance
Special applications Hygienic and washdown zones, Difficult application conditions
Items supplied Mounting nut, V4A stainless steel (2x)

1) With gold plated contact pins.

2) According to EN 60529.

3) According to ISO 20653:2013-03.

Mechanics/electronics

Supply voltage 10 V DC … 30 V DC
Ripple ≤ 10 %
Voltage drop ≤ 2 V 1)
Hysteresis 3 % … 20 %
Reproducibility ≤ 2 % 2) 3)
Temperature drift (of Sr) ± 10 %
EMC According to EN 60947-5-2
Continuous current Ia ≤ 200 mA
No load current ≤ 10 mA
Short-circuit protection ✔
Power-up pulse protection ✔
Shock and vibration resistance 100 g / 11 ms / 1000 cycles; 150 g / 1 Mio cycles; 10 Hz … 55 Hz, 1 mm / 55 Hz … 500 Hz / 15 g
Ambient operating temperature –40 °C … +100 °C
Housing material Stainless steel V4A, DIN 1.4404 / AISI 316L
Sensing face material Plastic, LCP
Housing length 60 mm
Thread length 28 mm
Tightening torque, max. Typ. 14 Nm
Protection class III
UL File No. E181493

1) At Ia max.

2) Supply voltage UB and constant ambient temperature Ta.

3) Of Sr.

Data Sheet: PDF
