Description

SAMSON 3277 Pneumatic Actuator

SAMSON Actuator Supplier in Bangladesh

Application

Linear actuators particularly suitable for mounting on SAMSON Series 240, 250, 280, 290 and SMS Valves as well as Type 3510 Micro-flow Valves

Actuator area 120 to 750v2 cm²

Rated travel  7.5 to 30 mm

Special features

The Type 3271 and Type 3277 Pneumatic Actuators are diaphragm actuators with a rolling diaphragm and internal springs.

– Low overall height

– Powerful thrust at high stroking speed

– Low friction

– Various bench ranges by varying the number of springs or changing the spring compression

– No special tools required to change the bench range or reverse the direction of action (including actuator with handwheel)

– Permissible operating temperatures from -60 to +120 °C

– Direct attachment of accessories on additional yoke for Type 3277 with concealed travel pickoff

Data Sheet: PDF
