Pepperl+Fuchs Photoelectric Slot Sensor GL30-IR/32/40a/98a

Key Benefits at a Glance

  • Optimized for the detection of small parts
  • High switching frequency
  • Multiple device installation possible, no mutual interference (no cross-talk)
  • Sensitivity adjuster and light-on/dark-on changeover switch as standard features of this series
  • Infrared light
  • Degree of protection IP67
  • cULus approval
  • Diecast zinc housing, powder coated
Category:
Tags:

Description

Pepperl+Fuchs Photoelectric Slot Sensor GL30-IR/32/40a/98a

Photoelectric Slot Sensor GL30-IR/32/40a/98a

Function GL30-IR/32/40a/98a

Photoelectric slot sensors offer vast installation benefits thanks to their housing design. When it comes to operation, these new generation devices boast features such as high resolution, high repeatability, automatic signal threshold adjustment, ambient light resistance, and detection of and/or light transmission through transparent objects. Cross-talk protection enables parallel installation of devices despite extremely high switching frequency. These characteristics guarantee reliable detection of small parts, from 0.3 mm, across the entire detection range, even in very fast moving applications.

Applications

• Small part detection, from object size 0.3 mm

• Can also be used for systems with strong vibrations

• Detection of small needles in transparent hollow needles

• Counting of small parts on conveyors

• Feed and correct separation verification

• Web edge control

• Elevator car position in

Technical data of GL30-IR/32/40a/98a

Photoelectric slot sensor, zinc pressure diecast housing, 30 mm slot width, infrared light, light/dark on, sensitivity adjuster, DC version, PNP output, 3 pin M8 plug

Light source IRED
Light type modulated infrared light
Tests EN 60947-5-2
Target size 0.3 mm
Slot width 30 mm
Slot depth 35 mm
Ambient light limit 100000 Lux

Function indicator LED red in connector
Control elements Sensitivity adjuster, light/dark switch

Operating voltage UB 10 … 30 V DC, class 2
Ripple 10 %
No-load supply current I0 ≤ 15 mA

Switching type light/dark on
Signal output 1 PNP, short-circuit protected, open collector
Switching voltage max. 30 V DC
Switching current max. 100 mA
Repeat accuracy 0.05 mm
Switching frequency f 2 kHz
Response time ≤ 250 µs

Degree of protection IP67
Connection M8 connector, 3-pin
Material
Housing powder coated diecast zinc
Optical face glass
Mass 60 g
Dimensions
Height 50 mm
Width 10 mm
Length 60 mm
