Pepperl+Fuchs NBN3-F31K2M-Z8L-B13-S-3G-3D

Pepperl+Fuchs Inductive Proximity Sensors | NBN3-F31K2M-Z8L-B13-S-3G-3D

  • Sensing range (max.): 2.5 mm
  • Output function: NO
  • Connection type: Screw terminals
  • Output Type: 2×2-wire
  • Installation type: Non-flush



For Price Call: 01329727092
Email: sales@voltecbd.com
Category:
Tags:

Description

Pepperl+Fuchs Inductive Proximity Sensors | NBN3-F31K2M-Z8L-B13-S-3G-3D

Pepperl+Fuchs Inductive Proximity Sensors

Pepperl+Fuchs Inductive Proximity Sensors Supplier in Bangladesh

Inductive Sensors

Pepperl+Fuchs provides an extensive range of inductive proximity sensors, delivering versatile application possibilities for various industries. Featuring an array of housing designs, diverse materials, and numerous output signals, these sensors come with global certifications and cutting-edge technologies. A selection of more than 6,000 sensors offers unparalleled flexibility when it comes to choosing the optimum sensor solution.
Inductive sensors are used across various industries, each with its unique demands. In the automotive industry, for instance, these sensors must withstand high temperatures and magnetic fields. The construction machinery industry requires sensors with enhanced pressure resistance. Pepperl+Fuchs offers a range of highly specialized sensors that meet these diverse challenges and are suited to any environmental condition.



NBN3-F31K2M-Z8L-B13-S-3G-3D AT A GLANCE
Benefits
  • Direct mounting on standard actuators
  • ATEX/IECEx Zone 2/22
  • Compatible with all process control systems
  • 2-wire DC sensor with minimum off-state current
  • Rugged metal base
  • Weatherproof housing for outdoor applications
  • Plug-in terminals

Technical details-

General specifications

Switching function 2 x normally open (NO)
Output type Two-wire with minimum off-state current
Rated operating distance sn 2.5 mm
Installation for non-flush mounting
Output polarity DC
Assured operating distance sa 0 … 2.05 mm
Output type 2x 2-wire



Mechanical specifications

Connection type screw terminals
Connection (system side) screw terminals , M20 x 1.5 cable gland , usable thread length 13.5 mm , screw-in depth max. 13.5 mm
ground connection with earthing screw only for wire cross-section 4 mm2, use solid wire or stranded wire with wire end ferrule
Connection (valve side) screw terminal ,
Cable gland M20 x 1.5
Housing material PC (glass-fiber-reinforced Makrolon)
Housing base powder coated aluminum
Degree of protection IP67 ; additional degree of protection IP66/IP69 with BT65-F31K2-RG-EN-01 and SH-F31K2-B13
Terminal assembly
Number 10
Connection type For connection of copper wires with 7 mm dismantle length
Tightening torque 0.5 … 0.6 Nm
Type Screw terminal block, pluggable
Terminal capacity Conductor cross-section 0,25 … 2,5 mm2 , flexible/rigid
For Multiple-wire connection: two wires of equal cross-section per 0.25 … 1 mm2
Tightening torque, fastening screws ≤ 5 Nm
Tightening torque, housing screws 1.5 Nm
Tightening torque, earthing screw 1.5 Nm
Tightening torque, cable gland M20 x 1.5 ; max. 11 Nm
Tightening torque, stopping plug 2 Nm
Dimensions
Height 53 mm
Width 100 mm
Length 106 mm



Datasheet: PDF
