OMRON E2EC-X4D2

OMRON Inductive Proximity Sensors | E2EC-X4D2

  • Sensing distance: 4 mm±10%
  • Response frequency: 1 kHz
  • Size: M12
  • Power supply voltage: 12 to 24 VDC (10 to 30 VDC) ripple (p-p): 10% max.



For Price Call: 01329727092
Email: sales@voltecbd.com
Category:
Tags:

Description

OMRON Inductive Proximity Sensors | E2EC-X4D2

OMRON Inductive Proximity Sensors

OMRON Inductive Proximity Sensors Supplier in Bangladesh

E2EC

Sub-miniature inductive sensor for demanding mounting conditions with remote amplifier

The E2EC family features the smallest sensor heads for reliable sensing in areas where mounting space is crucial. The miniature sizes of the sensing heads are achieved by separating the sensing part from the amplifier. In contrast to standard separate amplifier models the E2EC family simplifies the installation as the amplifier is built into the cable.



E2EC At A GLANCE

Features
  • 3 mm diameter sensing head for smallest spaces
  • 18 mm long ultra short M12 size housing
  • Full metal housing model for highest resistance in demanding environments

Technical details-

Specifications

Item

dia. 3

dia. 5.4

dia. 8

M12

E2EC-CR8D_

E2EC-C1R5D_

E2EC-MC

E2EC-QC

E2EC-C3D_

E2EC-X4D_

Sensing distance

0.8 mm±15%

1.5 mm±10%

2 mm±10%

3 mm±10%

4 mm±10%

Response frequency

1.5 kHz

100 Hz

1 kHz

Power supply voltage
(Operating voltage)

12 to 24 VDC (10 to 30 VDC) ripple (p-p): 10% max.

Protective circuits

Surge absorber, short-circuit protection

Ambient temperature

Operating

−25 to 70°C (with no icing or condensation)

Storage

Degree of protection

IEC60529 IP67

Material

Case

Brass

Stainless steel (SUS303)

Brass

Sensing surface

ABS

Stainless steel (SUS303)

ABS



Datasheet: PDF
