Leuze Throughbeam Photoelectric Sensor Receiver LE3C/6G-M8, 50137180

  • Device type: Receiver
  • Thread size: M8
  • Type: Male
  • Material: Metal
  • No. of pins: 4 -pin

Description

Leuze Throughbeam Photoelectric Sensor Receiver LE3C/6G-M8, 50137180

Leuze LE3C/6G-M8, 50137180

Throughbeam Photoelectric Sensor

Specifications:-

Basic Data:-

Series 3C
Operating principle Throughbeam principle
Device type Receiver

Optical Data:-

Operating range see transmitter

Electrical Data:-

Protective circuit Polarity reversal protection
Short circuit protected

Performance Data:-

Supply voltage UB 10 … 30 V, DC, Incl. residual ripple
Residual ripple 0 … 15 %, From UB
Open-circuit current 0 … 20 mA

Outputs:-

Number of digital switching outputs 2 Piece(s)

Switching Outputs:-

Type Digital switching output

Switching Outputs 1:-

Switching element Transistor, Push-pull
Switching principle Light switching (PNP)/dark switching (NPN)

Switching Outputs 2:-

Switching element Transistor, Push-pull
Switching principle Dark switching (PNP)/light switching (NPN)

Time Behavior:-

Switching frequency 1,000 Hz
Response time 0.5 ms
Readiness delay 300 ms

Connection:-

Number of connections 1 Piece(s)

Connection 1:-

Function Signal OUT
Voltage supply
Type of connection Connector
Thread size M8
Type Male
Material Metal
No. of pins 4 -pin

Mechanical Data:-

Dimension (W x H x L) 11.4 mm x 34.2 mm x 18.3 mm
Housing material Plastic
Plastic housing PC-ABS
Lens cover material Plastic / PMMA
Net weight 10 g
Housing color Red
Type of fastening Through-hole mounting
Via optional mounting device
Compatibility of materials ECOLAB

Operation & Display:-

Type of display LED
Number of LEDs 2 Piece(s)

Environmental Data:-

Ambient temperature, operation -40 … 60 °C
Ambient temperature, storage -40 … 70 °C

Data Sheet: Pdf
