Leuze Diffuse Sensor With Background Suppression HT3C.S/4P-200-M8, 50129382
- RANGE: 15-200 mm
- OUTPUT: PNP-LIGHT SWITCHING/DARK SWITCHING
- SUPPLY VOLTAGE: 10-30VDC
- CABLE WITH M8 CONNECTOR
- PLASTIC HOUSING
Description
Leuze Diffuse Sensor With Background Suppression HT3C.S/4P-200-M8, 50129382
HT3C.S/4P-200-M8, 50129382
Photoelectric Diffuse Sensor
Specifications:-
Basic Data:-
| Series | 3C |
| Operating principle | Diffuse reflection principle with background suppression |
| Application | Detection of small parts |
Special Version:
| Special version | Small light spot (S) |
Optical Data:
| Black-white error | < 10% up to 100 mm |
| Operating range | Guaranteed operating range |
| Operating range, white 90% | 0.005 … 0.2 m |
| Operating range, gray 18% | 0.01 … 0.15 m |
| Operating range, black 6% | 0.015 … 0.12 m |
| Operating range limit | 0.005 … 0.2 m |
| Operating range limit | Typical operating range |
| Adjustment range | 15 … 200 mm |
| Light source | LED, Red |
| Wavelength | 650 nm |
| Transmitted-signal shape | Pulsed |
| LED group | Exempt group (in acc. with EN 62471) |
Electrical Data:-
| Protective circuit | Polarity reversal protection Short circuit protected |
Performance Data:-
| Supply voltage UB | 10 … 30 V, DC, Incl. residual ripple |
| Residual ripple | 0 … 15 %, From UB |
| Open-circuit current | 0 … 15 mA |
Outputs:-
| Number of digital switching outputs | 2 Piece(s) |
Switching Outputs:-
| Type | Digital switching output |
Switching Outputs 1:-
| Switching element | Transistor, PNP |
| Switching principle | Light switching |
Switching Outputs 2:-
| Switching element | Transistor, PNP |
| Switching principle | Dark switching |
Time Behavior:-
| Switching frequency | 1,000 Hz |
| Response time | 0.5 ms |
| Readiness delay | 300 ms |
| Response jitter | 166 µs |
Connection:-
| Number of connections | 1 Piece(s) |
Connection 1:-
| Function | Signal OUT Voltage supply |
| Type of connection | Cable with connector |
| Cable length | 200 mm |
| Sheathing material | PUR |
| Cable color | Black |
| Wire cross section | 0.2 mm² |
| Thread size | M8 |
| Type | Male |
| Material | Metal |
| No. of pins | 4 -pin |
Mechanical Data:-
| Dimension (W x H x L) | 11.4 mm x 34.2 mm x 18.3 mm |
| Housing material | Plastic |
| Plastic housing | PC-ABS |
| Lens cover material | Plastic / PMMA |
| Net weight | 20 g |
| Housing color | Red |
| Type of fastening | Through-hole mounting Via optional mounting device |
| Compatibility of materials | ECOLAB |
Operation & Display:-
| Type of display | LED |
| Number of LEDs | 2 Piece(s) |
| Operational controls | Multiturn potentiometer |
| Function of the operational control | Range adjustment |
Environmental Data:-
| Ambient temperature, operation | -40 … 60 °C |
| Ambient temperature, storage | -40 … 70 °C |
Data Sheet: Pdf
