Description
Specifications:-
Basic Data:-
| Series |
318B |
| Operating principle |
Diffuse reflection principle |
Optical Data:-
| Operating range |
Guaranteed operating range |
| Operating range, white 90% |
0.001 … 0.215 m |
| Operating range, gray 50% |
0.001 … 0.19 m |
| Operating range, gray 18% |
0.003 … 0.15 m |
| Operating range, black 6% |
0.005 … 0.125 m |
| Operating range limit, white 90% |
0.001 … 0.28 m |
| Operating range limit, gray 50% |
0.001 … 0.245 m |
| Operating range limit, gray 18% |
0.003 … 0.19 m |
| Operating range limit, black 6% |
0.005 … 0.16 m |
| Operating range limit |
Typical operating range |
| Light source |
LED, Infrared |
| Wavelength |
850 nm |
| Transmitted-signal shape |
Pulsed |
| LED group |
Exempt group (in acc. with EN 62471) |
Electrical Data:-
| Protective circuit |
Polarity reversal protection
Short circuit protected |
Performance Data:-
| Supply voltage UB |
10 … 30 V, DC, Incl. residual ripple |
| Residual ripple |
0 … 15 %, From UB |
| Open-circuit current |
0 … 20 mA |
Outputs:-
| Number of digital switching outputs |
2 Piece(s) |
Switching Outputs:-
| Type |
Digital switching output |
Switching Outputs 1:-
| Switching element |
Transistor, NPN |
| Switching principle |
Light switching |
Switching Outputs 2:-
| Switching element |
Transistor, NPN |
| Switching principle |
Dark switching |
Time Behavior:-
| Switching frequency |
500 Hz |
| Response time |
1 ms |
| Readiness delay |
300 ms |
Connection:-
| Number of connections |
1 Piece(s) |
Connection 1:-
| Function |
Signal OUT
Voltage supply |
| Type of connection |
Cable |
| Cable length |
2,000 mm |
| Sheathing material |
PUR |
| Cable color |
Black |
| Number of conductors |
4 -wire |
| Wire cross section |
0.2 mm² |
Mechanical Data:-
| Dimension (Ø x L) |
18 mm x 46 mm |
| Thread size |
M18 x 1 mm |
| Housing material |
Plastic |
| Plastic housing |
ABS |
| Lens cover material |
Plastic |
| Net weight |
70 g |
| Housing color |
Black
Red |
Operation & Display:-
| Type of display |
LED |
| Number of LEDs |
1 Piece(s) |
| Operational controls |
Teach button |
Environmental Data:-
| Ambient temperature, operation |
-40 … 60 °C |
| Ambient temperature, storage |
-40 … 70 °C |
Data Sheet: Pdf
