Leuze 50128013

Leuze Fork Photoelectric Sensor GS 63B/6D-S8, 50128010

  • Series 63.
  • Principle of physics :-Optical.
  • Application Detection of non-transparent labels
  • Label width, min. 2 mm
    Label gap, min. 2 mm
  • Medium : Not transparent
Category:
Tags:

Description

Leuze Fork Photoelectric Sensor GS 63B/6D-S8, 50128010

Leuze GS 63B/6D-S8, 50128010

Leuze Fork Photoelectric Sensor

Fork sensors

Fork sensors combine transmitter and receiver into a single device and therefore feature high operational reliability. They are characterized by simple mounting without the need for alignment as well as high sensitivity. The fork sensors are used for detecting small parts or for detecting labels and print marks, even on transparent films.

Technical features:-

Basic Data:-

Series 63
Principle of physics Optical
Application Detection of non-transparent labels
Label width, min. 2 mm
Label gap, min. 2 mm
Medium Not transparent

Optical Data:-

Light source LED, Infrared
Wavelength 940 nm
Transmitted-signal shape Pulsed

Electrical Data:-

Protective circuit Polarity reversal protection
Short circuit protected

Performance Data:-

Supply voltage UB 10 … 30 V, DC
Residual ripple 0 … 15 %, From UB
Open-circuit current 0 … 30 mA

Outputs:-

Number of digital switching outputs 1 Piece(s)

Switching Outputs:-

Type Digital switching output
Voltage type DC
Switching current, max. 100 mA
Switching voltage high: ≥(UB-2V)
low: ≤ 2 V

Switching Outputs 1:-

Switching element Transistor, Push-pull
Switching principle Switching signal on label

Time Behavior:-

Switching frequency 10,000 Hz
Response time 0.05 ms
Readiness delay 300 ms
Max. conveyor speed during teach-in 20 m/min

Connection:-

Number of connections 1 Piece(s)

Connection 1:-

Function Signal OUT
Voltage supply
Type of connection Connector
Thread size M8
Type Male
Material Metal
No. of pins 4 -pin
Plug outlet Horizontal (parallel to belt movement)

Mechanical Data:-

Design Fork
Mouth width 3 mm
Mouth depth 61 mm
Dimension (W x H x L) 11 mm x 30 mm x 80 mm
Housing material Metal
Plastic
Metal housing Diecast zinc, chemically nickel-plated
Plastic housing PC
Lens cover material Plastic/PC
Net weight 55 g
Housing color Red
Silver
Type of fastening Through-hole mounting
Via optional mounting device

Operation & Display:-

Type of display LED
Number of LEDs 2 Piece(s)
Operational controls Multiturn potentiometer

Environmental Data:-

Ambient temperature, operation -20 … 60 °C
Ambient temperature, storage -30 … 70 °C

Data Sheet: Pdf
