Leuze 50118398

Leuze Fiber Optic Amplifier LV461.1/P2, 50118398

  • Suitable For: Glass Fiber Optics, Plastic Fiber Optics
  • Switching Output: PNP/NPN
  • Cable Type
  • Plastic Housing
  • Switching Frequency: 500Hz
Category:
Tags:

Description

Leuze Fiber Optic Amplifier LV461.1/P2, 50118398

Leuze LV461.1/P2, 50118398

Leuze Fiber Optic Amplifier

Fiber optic sensors

If space for sensors is particularly tight or extreme ambient conditions prevail, conventional cubic or cylindrical sensors quickly reach their limits. This is where fiber optic sensors provide an elegant solution. They consist of a two-part structure: flexible fiber optics made of plastic or glass and available in various lengths, and separate amplifiers with a wide range of evaluation options. This design makes it possible to place the amplifier outside the critical environment and install it in suitable locations while the fiber runs to the detection point. This means that even demanding conditions can be mastered reliably.

Amplifiers for fiber optics

The optical fibers are plugged into the amplifier. Depending on the model, the ranges of the fibers and the available functions vary. In addition to the basic requirements with 20-turn potentiometer for sensitivity adjustment with high resolution, also available are 2 switches for light/dark switching as well as versions with convenient, high-performance amplifiers with extensive adjustment options for operating ranges, sensitivities and time functions. The signal value, and at the same time the switching threshold, are shown on two easy-to-read displays. Three different teach modes simplify configuration. Also available as IO-Link variant.

Specifications:-

Basic Data:

Series 461
Suitable for Glass fiber optics
Plastic fiber optics

Optical Data

Light source LED, Red

Electrical Data
Performance Data

Supply voltage UB 12 … 24 V, DC

Outputs
Switching Outputs

Type Digital switching output

Switching Outputs 1

Switching element Transistor, PNP

Switching Outputs 2

Switching element Transistor, NPN

Time Behavior

Switching frequency 500 Hz

Connection
Connection 1

Type of connection Cable
Cable length 2,000 mm
Number of conductors 4 -wire

Mechanical Data

Design Cubic
Dimension (W x H x L) 10 mm x 31 mm x 62 mm
Housing material Plastic
Net weight 69 g

Operation and Display

Type of display LED
Operational controls Control buttons
Multiturn potentiometer

Data Sheet: Pdf
