KEYENCE Inductive Proximity Sensor ER-GM12PC
- SN: 4mm
- Output: PNP (NO/NC)
- Connection: M12
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
KEYENCE Inductive Proximity Sensor ER-GM12PC
KEYENCE ER-GM12PC
Keyence Inductive Sensor Supplier in Bangladesh
General-purpose all-metal shielded type Screw type M12 Connector PNP output Mid-Range
Specifications
| Model | ER-GM12PC | |||
| Type | General-purpose all-metal shielded type Screw type M12 Connector (M12 4-pin) PNP output Mid-Range | |||
| Power supply cable length | ― *1 | |||
| No. of control outputs | 2 | |||
| Output mode | Output 1 | N.O. | ||
| Output 2 | N.C. | |||
| Button | None | |||
| Button | Function | ― | ||
| Detecting distance | 4 mm 0.16″ ±10% *2 | |||
| Response frequency | 150 Hz *3 *4 | |||
| Hysteresis distance | 15% or less of detecting distance | |||
| Detectable object | Magnetic metal, Non-magnetic metal *5 | |||
| Standard detectable object (Iron, t = 1 mm 0.04″) | 12 × 12 mm 0.47″ × 0.47″ | |||
| Temperature characteristics | ±10% or less of detecting distance at +25°C +77°F (-25 to +55°C -13°F to +131°F) ±15% or less of detecting distance at +25°C +77°F (+55 to +70°C 131°F to 158°F) |
|||
| Control output | Open-collector, 30 VDC or less; 50 mA or less for 1 output; 50 mA or less in total for 2 outputs | |||
| Control output | Residual voltage | PNP output: 2.2 V or less (Output current: 10 mA or less) / 2.3 V or less (Output current: 10 to 50 mA) *6 | ||
| Power supply | Power voltage | 16 to 30 VDC (including 10% or less ripple (P-P)), Class 2 | ||
| Power consumption (excluding load current) | 1000 mW or less (42 mA or less at 24 V, 63 mA or less at 16 V) | |||
| Protection circuit | Protection against reverse power connections, output short-circuits, and reverse output connections | |||
| Environmental resistance | Enclosure rating | IP67 (IEC60529), IP67G (JIS C 0920) | ||
| Ambient temperature | -25 to +70°C -13°F to +158°F (no freezing) *7 | |||
| Relative humidity | Up to 95% RH (no condensation) | |||
| Vibration resistance | 10 to 500 Hz; Power spectral density: 0.816 G2/Hz; X, Y, and Z directions | |||
| Shock resistance | 1000 m/s2 3280.8 ft/s2 (100 G), 10 times in each of the X, Y, and Z directions |
|||
| Material | Detecting surface: SUS303, Mounting screw: SUS303, Case resin: PBT, Nut: SUS304, Toothed lock washer: SUS304 [Connector] Indicator: PBT (M8: LCP), Connector: PBT (M8: LCP), Case: SUS303 [Connector with pigtail] Indicator: TPU, Cable cap (M8 only): PBT, Cable: PVC, Connector resin: TPU, Connector metal: Nickel-plated brass [Cable] Indicator: TPU, Cable cap (M8 only): PBT, Cable: PVC |
|||
| Accessories | Nut ×2, Toothed lock washer ×1 | |||
| Weight | Approx. 35 g 1.24 oz | |||
| *1 Ensure the power cable is no longer than 30 m 98.4′ for connector and connector with pigtail types. *2 The distance at which a standard detectable object can be detected when the unit is mounted without being affected by surrounding metal. *3 Value when a standard detectable object is used, the distance between detectable objects is twice the standard detectable object, and the distance to the detectable object is 1/2 the detecting distance. *4 The response frequency varies depending on the operating temperature. The response frequency at temperatures of +55°C +131°F or higher is 50% of that at +25°C +77°F. *5 Detecting distance varies according to the material and size. See the characteristic diagrams for details. *6 Residual voltage is for when a 2 m 6.6′ cable is used. *7 The upper limit of the UL temperature rating is +55℃ +131℉. |
||||
More KEYENCE Models:
🔹 Keyence Ultra-long distance shielded type
- M8: ER-08N, ER-08N03C, ER-08P, ER-08P03C, ER-08PC, ER-08TPC
- M12: ER-12N, ER-12N03C, ER-12P, ER-12P03C, ER-12PC, ER-12TPC
- M18: ER-18N, ER-18N03C, ER-18P, ER-18P03C, ER-18PC
- M30: ER-30N, ER-30N03C, ER-30P, ER-30P03C, ER-30PC
🔹 Keyence General-purpose all-metal shielded type (Long-Range)
- M8: ER-GL08N, ER-GL08N03C, ER-GL08P, ER-GL08P03C, ER-GL08PC, ER-GL08TPC
- M12: ER-GL12N, ER-GL12N03C, ER-GL12P, ER-GL12P03C, ER-GL12PC, ER-GL12TPC
- M18: ER-GL18N, ER-GL18N03C, ER-GL18P, ER-GL18P03C, ER-GL18PC
- M30: ER-GL30N, ER-GL30N03C, ER-GL30P, ER-GL30P03C, ER-GL30PC
🔹 Keyence General-purpose all-metal shielded type (Mid-Range)
- M8: ER-GM08N, ER-GM08N03C, ER-GM08P, ER-GM08P03C, ER-GM08PC
- M12: ER-GM12N, ER-GM12N03C, ER-GM12P, ER-GM12P03C, ER-GM12PC
🔹 Keyence Environment-resistant all-metal shielded type
- M8: ER-GR08N, ER-GR08P, ER-GR08PC
- M12: ER-GR12N, ER-GR12P, ER-GR12PC
- M18: ER-GR18N, ER-GR18P, ER-GR18PC
🔹 Keyence General-purpose all-metal shielded type (Short-Range)
- M12: ER-GS12N, ER-GS12N03C, ER-GS12P, ER-GS12P03C, ER-GS12PC
🔹 Keyence Weld-resistant all-metal shielded type
- M8: ER-GW08N, ER-GW08P, ER-GW08PC
- M12: ER-GW12N, ER-GW12P, ER-GW12PC
- M18: ER-GW18N, ER-GW18P, ER-GW18PC
🔹 Keyence Compact all-metal shielded type
- ø4.5 Cylindrical: ER-M045N, ER-M045NC, ER-M045P, ER-M045PC
- M5 Screw: ER-M05N, ER-M05NC, ER-M05P, ER-M05PC
- Thin type (t = 4.7 mm): ER-M08FN, ER-M08FNC, ER-M08FP, ER-M08FPC
- M8 L-shape: ER-M08LN, ER-M08LNC, ER-M08LP, ER-M08LPC
- Thin type (t = 8 mm): ER-M18FN, ER-M18FNC, ER-M18FP, ER-M18FPC
🔹 Keyence Ultra-long distance unshielded type
- M8: ER-U08N, ER-U08P, ER-U08PC, ER-U08TPC
- M12: ER-U12N, ER-U12P, ER-U12PC, ER-U12TPC
- M18: ER-U18N, ER-U18P, ER-U18PC
- M30: ER-U30N, ER-U30P, ER-U30PC
🔹 Keyence Connector Cables
- M8: OP-87627, OP-87631, OP-89125, OP-89126, OP-89127, OP-89128, OP-89129, OP-89130, OP-89131, OP-89132, OP-89133, OP-89134, OP-89135
- M12: OP-87634, OP-87635, OP-87636, OP-87637, OP-87638, OP-87639, OP-87640, OP-87641
