HENGSTLER RI76TD/ 4096ED.4A24KF-K0 Incremental Encoder
- Through hollow shaft Ø 15 to 42 mm
- Outer diameter only 76 mm
- Easy to install thanks to clamping ring at front or rear
- Operating temperature up to 100°C
- Fields of application e.g. motors, Printing machines, Lifts
Description
HENGSTLER ICURO RI76TD/ 4096ED.4A24KF-K0 Incremental Encoder
HENGSTLER Incremental Encoder
Match Code: RI76TD/ 4096ED.4A24KF-K0
Item Number: 0534566
The high-accuracy RI76 hollow shaft incremental encoder has been specially designed for large shaft diameters up to 42 mm. The housing diameter is only 76 mm, which makes this encoder ideal for use in motors, lifts and printing machines.
Specifications:
General:
| Category | Specification |
|---|---|
| Description | High-accuracy RI76 hollow shaft incremental encoder; designed for large shaft diameters up to 42 mm; housing Ø 76 mm; ideal for motors, lifts, printing machines |
| Function | Incremental |
| Product Family | RI76TD |
| Technology | Optical |
| Highlighted Features | Function: Incremental; Housing Diameter: 76 mm; Shaft Type: Through hollow shaft |
Mechanical:
| Category | Specification |
|---|---|
| Axial Endplay Mounting | 2 |
| Connection | TPE cable, radial |
| Housing Material | Aluminium |
| Housing Diameter | 76 mm |
| Mounting of Housing | Continuous hollow shaft with clamping ring at the front |
| Protection Shaft | IP64 |
| Radial Endplay Mounting | 0.15 |
| Revolution (continuous) | 3600 RPM |
| Shaft Diameter | 24 mm |
| Shaft Size | 24 mm |
| Shaft Type | Through hollow shaft |
| Shaft Material | Stainless Steel |
| Shock Resistance | 1000 m/s² (6 ms) |
| Tether Type | Spring plate, flexible, single |
| Vibration Resistance | 100 m/s² (10–2000 Hz) |
Electrical:
| Category | Specification |
|---|---|
| Cable Length | 10 m |
| Number of Pulses | 4096 PPR |
| Standard Output Version | Push-pull (K): A, B, N, Alarm/ |
| Supply Voltage | DC 10 – 30 V |
Environmental:
| Category | Specification |
|---|---|
| Certification | CE, c UL us (listed) |
| Maximum Operating Temp. | 100 °C |
| Maximum Storage Temp. | 100 °C |
| Minimum Operating Temp. | -40 °C |
| Minimum Storage Temp. | -25 °C |
| Protection Class | IP65 |
| Protection Class Housing | IP65 |
| Protection Tmp | 4 |
Datasheet: PDF
