DATALOGIC/DATASENSING Capacitive Proximity Sensors | CQ55/BN-3E

  • Sensing range (max.): 4 – 25mm
  • Connection type: M12 plug
  • Switching output: NPN
  • Output function: NO/NC
  • Switching frequency: 50 Hz
  • Installation type: Shielded/Unshielded



For Price Call: 01329727092
Email: sales@voltecbd.com

Description

DATALOGIC/DATASENSING Capacitive Proximity Sensors | CQ55/BN-3E

DATALOGIC/DATASENSING Capacitive Proximity Sensors

DATALOGIC/DATASENSING Capacitive Proximity Sensors supplier in Bangladesh

CQ55

Compact housing with sensitivity adjustment. Detection of all types of materials: solids, liquids, powders.

  • Designed for industrial application. Enhanced immunity to EM noises
CQ55/BN-3E AT A GLANCE
  • DC supply voltage
  • Adjustable sensitivity
  • Flat polycarbonate plastic housing

Technical details-

Detection properties
Nominal sensing distance 4…25mm
Thermal drift of Sr < 20%
Repeat Accuracy 5%
Sensitivity adjustment Yes
Hysteresis ≤ 20%
Outputs
Output type NPN
Output Function NO + NC
Switching frequency 50Hz
Electrical data
Operating Voltage 10…40Vdc
No-Load supply current ≤ 10mA
Load current ≤200mA
Leakage current ≤ 10μA
Output voltage drop 2,5Vmax @IL=200mA
Max ripple content ≤10%
LED indicators Yellow LED (object detected)
Time delay before availability ≤100ms
Short-circuit protection Yes, autoreset
Reverse Polarity Protection Yes
Impulsive Overvoltage Protection Yes
Mechanical data
Dimensions 55x35x15mm
Mounting Shielded/Unshielded
Housing material PC
Weight 65g
Connections M12 plug
Active Head Material PC
Operating temperature -25°C…+80°C (without freeze)
Storage temperature -40°C…+85°C
Diameter/Dimension 55x35x15mm



Datasheet: PDF

More capacitive proximity sensors :

DATALOGIC/DATASENSING CQ55/BN-3A, DATALOGIC/DATASENSING CQ55/BP-3A, DATALOGIC/DATASENSING CQ55/BP-3E
