DANFOSS Decentral Drive VACON® 100X series 380 – 480 VAC | 132H0507

  • Current Rating: 4.8 A
  • Frequency: 50 Hz
  • Operating voltage: 380-480 VAC



For Price Call: 01329727092
Email: sales@voltecbd.com

Description

DANFOSS Decentral Drive VACON® 100X series 380 – 480 VAC | 132H0507

DANFOSS Decentral Drive

DANFOSS Decentral Drive Supplier in Bangladesh

DANFOSS Decentral Drive AT A GLANCE

Achieve maximum performance in extreme environments. This AC drive withstands high-pressure water, high vibration levels, heat and dirt. A Gore® vent membrane, IP66 / Type 4X outdoor enclosure, and an operating temperature range from -40°C to +60°C give you full freedom for unlimited outdoor installations. With power range extending up to 37 kW, this drive makes the benefits of decentralized solutions available for a wide range of applications.

Technical Details

Gross weight 9.55 Kilogram
Net weight 8.8 Kilogram
Volume 0.311 Hectoliter
EAN 5714853290871

Product Group VACON VACON
Product Series 0100 VACON 100
Input type -3L -3L
Current -0004 4
Current Description 4,8 AMP 4,8 AMP
Mains Voltage -4 (-4) 380 – 480 Vac
Segment -X Vacon 100X
Regional -R00 International
Customized +BM1X Vacon0100 product
Terminal Box +TBOX (+TBOX) Basic Terminal Box
Brake +DBIN (+DBIN) Brake Chopper
Frequency setting +LS50 (+LS50) 50 Hz
Display Units +LSSI Metric Units of Measure
Documentation level +DQCK (+DQCK) Quick Guide
Firmware Language Pack +FL01 UK, DE, FI, SE, IT, FR lang
SW Package +F0072 (+F0072) GP System Software
EMC level +EMC2 C2 Commercial&Industry Environ
Marine Approval +E000 (+E000) No Marine Approval
Application +A0000 (+A0000)No Special Application
Internal FB selection +FBM2 Modbus, Backnet, N2 (+FBM2)
Keypad +HMGR Graphical Keypad
Real Time Clock Battery +SRNO No Battery for real time clock
D Slot Option Board +SD00 No board
E Slot Option Board +SE00 No board
Additional Equipment A +QDSS (+QDSS) Main Switch only
Additional Equipment B +Q000 (+Q000) No add. Equipment B
Additional Equipment C +Q000 No add. Equipment C
Shipping Package +GSCB Standard Packaging Material
UL Approval +GAUL (+GAUL) UL Approval
CE Aproval +GACE (+GACE) CE Approval
C-tick Approval +GACT (+GACT) C-Tick Approval
KC Approval +GAKC (+GAKC) KC Approval
Frame Size MM4 MM 04
Product Catalog NO_VIEW NO VIEW
Modelcode01 VACON0100-3L-0004-4-X
Modelcode04 +HMGR
Modelcode05 +QDSS
Calculated Net Weight [kg] 8.8
Calculated Gross Weight [kg] 9.55
Dimensions WxHxD [mm] 191X316X197 191X316X197
ECCN US 3A999.a 3A999.a
ECCN EU Y901 Y901



Datasheet: PDF
