BAUMER O300.EL-GW1B.72N

BAUMER Photoelectric Proximity Sensors O300.EL-GW1B.72N | Part No: 11176843

  • Functional principle: Through-beam photoelectric sensor
  • Sensing range (max.): 40 m
  • Connection type: Connector M8 4 pin
  • Output function: Light / dark operate



For Price Call: 01329727092
Email: sales@voltecbd.com
Category:
Tags:

Description

BAUMER Photoelectric Proximity Sensors O300.EL-GW1B.72N | Part No: 11176843

BAUMER Photoelectric Proximity Sensor

BAUMER Photoelectric Proximity Sensors supplier in Bangladesh

A new definition of reliability

  • Outstanding reliability even on deep black, shiny, transparent or irregular surfaces
  • Excellent precision and reproducibility
  • Simple design-in, installation and setup
  • More digital information thanks to IO-Link
Features
  • receiver
  • through beam sensor
  • 40 m
  • push-pull
  • qTeach / remote
  • connector M8 4 pin
  • -25 … 60 °C
  • IP 67

Technical details-

General data

Property Value
Type Photoelectric through beam sensor
Emitter / receiver Receiver
Actual range Sb 40 m
Nominal range Sn 75 m
Alignment / soiled lens indicator Flashing light indicator
Light indicator LED yellow
Power on indication LED green
Sensitivity adjustment qTeach / remote
Alignment optical axis less than 2°



Electrical data

Property Value
Response time / release time less than 0.49 ms
Voltage supply range +Vs 10 … 30 VDC
Current consumption max. (no load) 40 mA
Current consumption typ. 30 mA
Voltage drop Vd less than 3 VDC
Output function Light / dark operate
Output circuit Push-pull
Output current 100 mA
Short circuit protection Yes
Reverse polarity protection Yes



Datasheet: PDF
