BAUMER I40.P0HS-F22.NC1Z.7SCV

BAUMER Inductive Proximity Sensor I40.P0HS-F22.NC1Z.7SCV | Part No: 11725704

  • Sensing range (max.): 0.8 mm
  • Connection type: Cable, L=2 m
  • Switching output: NPN
  • Output function: NC
  • Switching frequency: 3 kHz
  • Installation type: Flush



For Price Call: 01329727092
Email: sales@voltecbd.com
Category:
Tags:

Description

BAUMER Inductive Proximity Sensor I40.P0HS-F22.NC1Z.7SCV | Part No: 11725704

BAUMER Inductive Proximity Sensor

BAUMER Inductive Proximity Sensors supplier in Bangladesh

Highly versatile inductive proximity switches

Extreme reliability and sustainable cost-efficiency

  • Cubic, flat or cylindrical designs from 3 mm to M30
  • Long-term stable switching distances up to 3 x Sn
  • Leading in EMC immunity, shock and vibration resistance
  • Unrivalled price-performance ratio
Features
  • Rectangular miniature sensor for tight spaces
  • Lowest serial dispersion due to end-of-line calibration
  • Robust even in demanding environments
  • Temperature and long-term stable switching behavior

Technical details-

General data

Property Value
Mounting type Flush
Nominal sensing distance Sn 0.8 mm
Assured sensing distance Sa ≤ 81 % of Sn
Real sensing distance Sr ± 10 % von Sn
Temperature drift ± 10 % of Sr
Hysteresis 2 … 20 % of Sr
Output indicator LED red (backside)
Correction factor typ. Mild steel 100 %, stainless steel 80 %, aluminum 65 %, copper 55 %
Reference object Fe360 4 x 4 x 1 mm



Electrical data

Property Value
Switching frequency 3 kHz
Voltage supply range +Vs 6 … 30 VDC
Current consumption max. (no load) 12 mA
Output circuit NPN break function (NC)
Voltage drop Vd less than 2 VDC
Output current 100 mA
Short circuit protection Yes
Reverse polarity protection Yes



Datasheet: PDF
