BAUMER Capacitive Proximity Sensor CFAK 22U9500/AMP | Part No: 11149600
- Connection type: Connector AMPSEAL 16 3 pin
- Output Type: Voltage output
- Installation type: Non Flush
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
BAUMER Capacitive Proximity Sensor CFAK 22U9500/AMP | Part No: 11149600
BAUMER Capacitive Proximity Sensor
BAUMER Capacitive Proximity Sensors supplier in Bangladesh
Proximity switch for non-contact detection of liquid as well as solid objects and bulk solids
- High switching distance up to 15 mm
- Detection through plastic walls
- Absolutely reliable even when interfered by ambient conditions, e.g. ambient light or dirt
- Objects such as wafers, PCBs, paper stacks, plastic containers or powders and granulates as well as liquids are perfectly detected
CFAK 22U9500/AMP At A GLANCE
- voltage output
- connector AMPSEAL 16 3 pin
- -40 … 85 °C
- IP 69K
Technical details-
General data
| Property | Value |
| Special type | Liquid level sensor for oil |
| Mounting type | Non-flush |
| Version | Adhesion resistant |
| Measurement type | Contact with medium |
| Approvals/certificates | EN 60947-5-2 / EN 60947-5-7, EN ISO 14982:2009, ISO 15003:2006, Sec 5.13, ISO 13766:2006-05, EN 13309:2010 |
Electrical data
| Property | Value |
| Voltage supply range +Vs | 4.75 … 5.25 VDC |
| Current consumption max. (no load) | 42 mA |
| Current consumption typ. | 10 mA |
| Output circuit | Voltage output |
| Output state |
In air 2,75 … 3,25 V In liquid 1,25 … 1,75 V Fault 0,50 … 1,00 V |
| Typ. response time | less than 1000 ms |
| Load resistance | ≥ 930 Ohm |
| Capacitive load | less than 200 nF |
| Short circuit protection | Yes |
| Reverse polarity protection | No |
Datasheet: PDF
