ALLEN BRADLEY 1766-L32AWA

Allen‑Bradley Controllers MicroLogix 1400 | 1766-L32AWA

  • Class: Progmable Logic Controller
  • Input Signal: 120 VAC
  • Output Signal: Relay
  • Power Supply: 120/240VAC



For Price Call: 01329727092
Email: sales@voltecbd.com
Category:
Tags:

Description

Allen‑Bradley Controllers MicroLogix 1400 | 1766-L32AWA

Allen‑Bradley Controllers

Allen‑Bradley Controllers supplier in Bangladesh

Bulletin 1766 MicroLogix™ 1400 Programmable Logic Controller Systems build upon critical MicroLogix 1100 features: EtherNet/IP™, on-line editing and a built-in LCD panel. These controllers feature a higher I/O count, faster high-speed counter, pulse train output, enhanced network capabilities and backlight on the LCD panel. Controllers without embedded analog I/O points provide 32 digital I/O points, while analog versions offer 32 digital I/O points and 6 analog I/O points. You can expand all versions with up to seven 1762 expansion I/O modules.

  • Ethernet port provides Web server capability, email capability and protocol support for DNP3 protocol support
  • Built-in LCD with backlight lets you view controller and I/O status
  • Built-in LCD provides simple interface for messages, bit/integer monitoring and manipulation
  • Expands application capabilities through support for as many as seven 1762 MicroLogix Expansion I/O modules with 256 discrete I/O
  • As many as six embedded 100 kHz high-speed counters (only on controllers with DC inputs)
  • Two serial ports with DF1, DH-485, Modbus RTU, DNP3, and ASCII protocol support
  • 10 KB words in user program memory with 10 KB words in user data memory
  • Up to 128 KB for data logging and 64 KB for recipe
  • Programmed with RSLogix 500® software

Typical applications include:

  • Material Handling
  • Packaging Applications
  • General Industrial Machinery
  • Printing
  • Food and Beverage
  • Pharmaceutical
  • Water Wastewater / SCADA
  • Clutch/Brake control
  • Position Control – Pick-and-place / Conveyor

Technical details-

General data

Class
Progmable Logic Controller
Communication
DF1, DH-485, Modbus RTU, ASCII, DNP3, EtherNet/IP messaging, DNP3 over IP, Modbus TCP/IP
Controller
MicroLogix 1400, 20 digital
Depth
87
Embedded Analog
None
Height
90
Input Signal
120 V AC
Interface
Ethernet Port, Isolated
Memory
20 KB
Number Of Channels
20 I/P, 12 O/P
Output Signal
Relay
Power Supply
120/240V AC



Datasheet: PDF

More Controllers:

Allen‑Bradley 1766-MM1, Allen‑Bradley 1766-L32BWA, Allen‑Bradley 1766-L32BXBA, Allen‑Bradley 1766-L32AWAA, Allen‑Bradley 1766-L32BWAA, Allen‑Bradley 1766-L32BXB
