SIEMENS SIMATIC S7-1200 G2

SIEMENS Basic Controllers | SIMATIC S7-1200 G2

  • Controller interface: 2-port PROFINET IO controller interface
  • Input voltage: 120 -240 V



For Price Call: 01329727092
Email: sales@voltecbd.com
Category:
Tags:

Description

SIEMENS Basic Controllers | SIMATIC S7-1200 G2

Siemens Basic Controllers

SIEMENS Basic Controllers supplier in Bangladesh

S7-1200 G2 AT A GLANCE

SIMATIC S7-1200 G2 Controllers are the successor generation to the S7-1200 and the right choice for compact automation solutions with integrated I/Os, communication and technology functions for automation tasks in the low to medium performance range. They are available in standard and fail-safe versions.

The scalable SIMATIC S7-1200 G2 Controllers feature integrated inputs and outputs as well as communication options, and allow modular expansion. Digital and analog input and output modules as well as different communications and special modules enable flexible adaptation to the relevant automation task.

Benefits

Efficient engineering

The seamless integration of SIMATIC Controllers into the common TIA Portal engineering framework permits the integrated storage of data, the smart library concept, and a uniform operating philosophy. This makes the use of universal functions particularly easy.

Variety of diagnostic options

An efficient error analysis and fast error localization with the new uniform display concept – plain text information on the error message in TIA Portal, on the HMI, and in the web server – shortens commissioning times and minimizes production downtimes. SIMATIC S7-1200 G2 offers you a diagnostic functionality that is already integrated in the system, without the need for any further programming.

Innovative design

The SIMATIC S7-1200 G2 Basic Controller can be perfectly adapted to the automation task at hand thanks to its comprehensive expansion options. The modular board concept permits an easy expansion of the controller without changing the physical size. Depending on the CPU type, up to 2 boards can be optionally plugged in. Devices can be replaced easily without rewiring due to replaceable PushIn terminal blocks.

Safety Integrated

Fail-safe automation is as easy to program as standard automation, and PROFIsafe devices are connected via PROFINET.

Technology Integrated

Efficient Motion Control applications, such as cam function or interpolation, fast counting and measuring tasks, as well as closed-loop control systems (PID) are integrated and can be implemented without additional expansion boards.

Security Integrated

Secure communication and access protection prevent manipulation and thus protect your process.

Technical details-

Degree of protection IP20 according to IEC 529
Ambient temperature
  • Operation
    (95% air humidity)
  • For horizontal installation
 -20 … +60 °C
  • For vertical installation
 -20 … +50 °C
  • Transport and storage
 -40 … +70 °C
  • With 95% air humidity
 25 … 55 °C
Isolation
  • 5/24 V DC circuits
 500 V AC test voltage
  • 115/230 V AC circuits to ground
 1500 V AC test voltage
  • 115/230 V AC circuits to 115/230 V AC circuits
 1500 V AC test voltage
  • 230 V AC circuits to 5/24 V DC circuits
 1500 V AC test voltage
  • 115 V AC circuits to 5/24 V DC circuits
 1500 V AC test voltage
Electromagnetic compatibility Requirements of the EMC directive
  • Immunity according to
    EN 50082-2
 Test acc. to:
IEC 801-2, IEC 801-3, IEC 801-4, EN 50141, EN 50204, IEC 801-5, VDE 0160
  • Interference according to EN 50081-1 and
    EN 50081-2
 Test according to
EN 55011, Class A,
Group 1
Mechanical stress
  • Vibration, test according to/tested with
 IEC 68, Part 2-6:
10 … 57 Hz;
constant amplitude
0.3 mm;
58 … 150 Hz;
constant acceleration 1 g (mounting on DIN rail) or
2 g (mounting in control panel);
vibration mode:
frequency sweeps with a rate of change of 1 octave/minute;
oscillation period:
10 frequency sweeps per axis in each direction of the three mutually perpendicular axes
  • Shock, test according to/tested with
 IEC 68, Part 2-27/half-sine:
magnitude of shock 15 g (peak value), duration 11 ms, 6 shocks in each of the three mutually perpendicular axes



Datasheet: PDF
