ALLEN BRADLEY 1746-NIO4I

Allen‑Bradley Analog Current Output Module | 1746 NIO4I

  • Class: Progmable Logic Controller
  • Input Signal: -20 to +20 mA (or) -10to +10V
  • Output Signal: 0 to 20 mA
  • Number Of Channels: 2 Input, 2 Output



For Price Call: 01329727092
Email: sales@voltecbd.com
Category:
Tags:

Description

Allen‑Bradley Analog Current Output Module | 1746 NIO4I

Allen‑Bradley Analog Current Output Module

Allen‑Bradley Analog Current Output Module supplier in Bangladesh

The Allen-Bradley 1746-NIO4I is a single-slot analog combination module designed for the SLC 500 series, featuring two analog inputs and two analog outputs. Operating with a common-mode voltage range of -20 to 20 V, the unit provides effective signal noise filtering with a common-mode rejection ratio of 105 dB and a normal-mode rejection ratio of 55 dB, both measured at 60 Hz.
Power is drawn directly from the SLC 500 backplane, requiring 55 mA at 5 V DC and 145 mA at 24 V DC. Unlike comparable modules that support external power configurations, the 1746-NIO4I relies strictly on backplane power for operation.

Technical details-

General data

Manufacturer Allen-Bradley / Rockwell Automation
Series SLC 500
Part Number 1746-NIO4I
Product Type Combination I/O Module
Channels. 4 Non-isolated
Number of Outputs 4 current outputs (0…20 mA),
Individually isolated no
Backplane Current Load 55 mA @ 5V, 195 mA @ 24V
Step Response @ 95% 2.5 ms
Resolution (bits), Max 14
Non–linearity 0.05%
Conversion Method R-2R Ladder
Load Range 0 to 500 Ohms
Maximum Load Reactance 100 µH
Full Scale 21 mA
Overall Accuracy at +25° C (77° F) (max.) ±0.298% of full scale.
Shipment Weight 0.393 kg
Shipment Dimensions 22 × 16 × 6 cm

Datasheet: PDF
