DATALOGIC_DATASENSING CT1_AN-2A

DATALOGIC/DATASENSING Capacitive Proximity Sensors | CT1/AN-2A

Category:

Description

DATALOGIC/DATASENSING Capacitive Proximity Sensors | CT1/AN-2A

DATALOGIC/DATASENSING Capacitive Proximity Sensors

DATALOGIC/DATASENSING Capacitive Proximity Sensors supplier in Bangladesh

CT

Detection of all types of materials: solids, liquids, powders.

  • Sensitivity adjustment with trimmer
  • Metal housing
  • IP65 protection degree
  • Complete protection against electrical damages
  • Axial cable exit or M12 plug cable exit
CT1/AN-2A AT A GLANCE
  • Sensitivity adjustment with trimmer
  • Metal housing
  • IP65 protection degree
  • Complete protection against electrical damages
  • Axial cable exit or M12 plug cable exit

Technical details-

Detection properties
Nominal sensing distance 2…20mm
Thermal drift of Sr < 20%
Repeat Accuracy 10%
Sensitivity adjustment Yes
Hysteresis ≤ 20%
Outputs
Output type NPN
Output Function NO
Switching frequency 100Hz
Electrical data
Operating Voltage 10…30Vdc
No-Load supply current ≤ 8mA
Load current ≤ 200mA
Leakage current ≤ 10mA
Output voltage drop 0,75/1,8V max @ IL=10/200 mA
Max ripple content ≤10%
LED indicators Green LED power, red LED (object detected)
Time delay before availability ≤100ms
Short-circuit protection Yes, autoreset
Reverse Polarity Protection Yes
Impulsive Overvoltage Protection Yes
Mechanical data
Dimensions M30 / L = 87mm
Mounting Unshielded
Housing material Nickel-plated brass
Weight 260g
Connections 2m PVC cable
Active Head Material PBT
Tightening torque 50Nm
Operating temperature -25°C…+70°C
Diameter/Dimension M30



Datasheet: PDF
