TURCK BIM-IKM-AP6X2-H1141_S34

TURCK Magnetic Sensors BIM-IKM-AP6X2-H1141/S34 | Part no: 46272

  • Operating voltage: 10 – 30 VDC
  • Connection type: Connector, M12 × 1
  • Switching output: PNP
  • Output function: NO



For Price Call: 01329727092
Email: sales@voltecbd.com
Category:
Tags:

Description

TURCK Magnetic Sensors BIM-IKM-AP6X2-H1141/S34 | Part no: 46272

TURCK Magnetic Sensors

TURCK Magnetic Sensors supplier in Bangladesh

Magnetic Sensors

Magnetic position sensors are typically used on pneumatic cylinders that have internal magnets and non-ferrous housings. Turck has developed a number of different sensor housings and accessories that allow a designer to mount a BIM sensor on all common pneumatic air cylinders. In addition, Turck offers barrel sensor housings that can be used with external magnets for position applications.

Features
  • Rectangular, height 34 mm
  • Metal, GD-Zn
  • Magnetic-inductive sensor
  • Weld resistant to AC fields of 50…60 Hz
  • DC 3-wire, 10…30 VDC
  • NO contact, PNP output
  • Male connector, M12 x 1

Technical data

Construction size 34 x 17 x 34 mm, IKM
Cylindrical design Tie-rod cylinder, Profile cylinder, Cylinder with external dovetail groove
Operating voltage 10…30 VDC
Output function NO contact, PNP
Electrical connection Connector, M12 × 1
Housing material Metal, GD-Zn
Ambient temperature -25…+70 °C
Protection class IP67
Special features Resistant to magnetic fields



Datasheet: PDF
