SIEMENS Comfort Panel | KTP400 series | 6AV2124-2DC01-0AX0
- Supply Voltage: 24 V DC
- Input current: 0.13 A
- Active power input: 3.1 W
For Price Call: 01326 708335
Email: sales@voltecbd.com
Description
SIEMENS Comfort Panel | KTP400 series | 6AV2124-2DC01-0AX0
SIEMENS Comfort Panel
SIEMENS Comfort Panel supplier in Bangladesh
Comfort Panel
- Excellent HMI functionality for demanding applications
- Widescreen TFT displays with 4″, 7″, 9″, 12″, 15″, 19″ and 22″ diagonals (all 16 million colors) with up to 40% more visualization area as compared to the predecessor devices
- Integrated high-end functionality with archives, scripts, PDF/Word/Excel viewer, Internet Explorer, Media Player and Web Server
- Dimmable displays from 0 to 100% via PROFIenergy, via the HMI project or via a controller
- Modern industrial design, cast aluminum fronts for 7″ upwards
- Upright installation for all touch devices
- Data security in the event of a power failure for the device and for the SIMATIC HMI Memory Card
- Innovative service and commissioning concept
- Maximum performance with short screen refresh times
- Suitable for extremely harsh industrial environments thanks to extended approvals such as ATEX 2/22 and marine approvals
- All versions can be used as an OPC UA client or as a server
- Key-operated devices with LED in every function key and new text input mechanism, similar to the keypads of mobile phones
- All keys have a service life of 2 million operations
- Configuring with the WinCC engineering software of the TIA Portal engineering framework
Technical details-
| General information | ||
| Product type designation | KTP400 Comfort | |
| Display | ||
| Design of display | TFT | |
| Screen diagonal | 4.3 in | |
| Display width | 95 mm | |
| Display height | 53.8 mm | |
| Number of colors | 16 777 216 | |
| Resolution (pixels) | ||
| ● Horizontal image resolution | 480 pixel | |
| ● Vertical image resolution | 272 pixel | |
| Backlighting | ||
| ● MTBF backlighting (at 25 °C) | 80 000 h | |
| ● Backlight dimmable | Yes; 0-100 % | |
| Control elements | ||
| Keyboard | ||
| ● Function keys | ||
| — Number of function keys | 4 | |
| — Number of function keys with LEDs | 4 | |
| ● Keys with LED | Yes | |
| ● System keys | No | |
| ● Numeric keyboard | Yes; Onscreen keyboard | |
| ● alphanumeric keyboard | Yes; Onscreen keyboard | |
| Touch operation | ||
| ● Design as touch screen | Yes; Analog-resistive | |
| Expansions for operator control of the process | ||
| ● DP direct LEDs (LEDs as S7 output I/O) | ||
| — F1…Fx | 4 | |
| ● Direct keys (keys as S7 input I/O) | ||
| — F1…Fx | 4 | |
| ● Direct keys (touch buttons as S7 input I/O) | 32 | |
| Installation type/mounting | ||
| Mounting position | vertical | |
| Wall mounting/direct mounting | No | |
| Mounting in portrait format possible | Yes | |
| Mounting in landscape format possible | Yes | |
| maximum permissible angle of inclination without external ventilation | 35° | |
| Supply voltage | ||
| Type of supply voltage | DC | |
| Rated value (DC) | 24 V | |
| permissible range, lower limit (DC) | 19.2 V | |
| permissible range, upper limit (DC) | 28.8 V | |
| Input current | ||
| Current consumption (rated value) | 0.13 A | |
| Starting current inrush I²t | 0.5 A²·s | |
| Power | ||
| Active power input, typ. | 3.1 W | |
| Processor | ||
| Processor type | ARM | |
| Storage | ||
| Flash | Yes | |
| RAM | Yes | |
| Memory available for user data | 4 Mbyte | |
| Type of output | ||
| Info LED | No | |
| Power LED | No | |
| Error LED | No | |
| Acoustics | ||
| ● Buzzer | Yes | |
| ● Speaker | No | |
| Time of day | ||
| Clock | ||
| ● Hardware clock (real-time) | Yes | |
| ● Software clock | Yes | |
| ● retentive | Yes; Back-up duration typically 6 weeks | |
| ● synchronizable | Yes | |
| Interfaces | ||
| Number of industrial Ethernet interfaces | 1 | |
| Number of RS 485 interfaces | 1; RS 422 / 485 combined | |
| Number of RS 422 interfaces | 1 | |
| Number of RS 232 interfaces | 0 | |
| Number of USB interfaces | 1; USB 2.0 | |
| ● USB Mini B | 1; 5-pole | |
| Number of 20 mA interfaces (TTY) | 0 | |
| Number of parallel interfaces | 0 | |
| Number of SD card slots | 2 | |
| With software interfaces | No | |
| Industrial Ethernet | ||
| ● Industrial Ethernet status LED | 2 | |
| ● Number of ports of the integrated switch | 1; No switch integrated | |
| Protocols | ||
| PROFINET | Yes | |
| Supports protocol for PROFINET IO | Yes | |
| IRT | No | |
| PROFIBUS | Yes | |
| EtherNet/IP | Yes | |
| MPI | Yes | |
| Protocols (Ethernet) | ||
| ● TCP/IP | Yes | |
| ● DHCP | Yes | |
| ● SNMP | Yes | |
| ● DCP | Yes | |
| ● LLDP | Yes | |
| WEB characteristics | ||
| ● HTTP | Yes | |
| ● HTTPS | No | |
| ● HTML | Yes | |
| ● XML | No | |
| ● CSS | Yes | |
| ● Active X | No | |
| ● JavaScript | Yes | |
| ● Java VM | No | |
| Redundancy mode | ||
| Media redundancy | ||
| — MRP | No | |
| Further protocols | ||
| ● CAN | No | |
| ● MODBUS | Yes | |
| Interrupts/diagnostics/status information | ||
| Diagnoses | ||
| ● Diagnostic information readable | Yes; S7 controller | |
| EMC | ||
| Emission of radio interference acc. to EN 55 011 | ||
| ● Limit class A, for use in industrial areas | Yes | |
| ● Limit class B, for use in residential areas | No | |
| Degree and class of protection | ||
| IP (at the front) | IP65 | |
| IP (rear) | IP20 | |
| NEMA (front) | ||
| ● Enclosure Type 4 at the front | Yes | |
| ● Enclosure Type 4x at the front | Yes | |
| Standards, approvals, certificates | ||
| CE mark | Yes | |
| cULus | Yes | |
| RCM (formerly C-TICK) | Yes | |
| KC approval | Yes | |
| Use in hazardous areas | ||
| ● ATEX Zone 2 | Yes | |
| ● ATEX Zone 22 | Yes | |
| ● IECEx Zone 2 | Yes | |
| ● IECEx Zone 22 | Yes | |
| ● cULus Class I Zone 1 | No | |
| ● cULus Class I Zone 2, Division 2 | Yes | |
| ● FM Class I Division 2 | Yes | |
| Marine approval | ||
| ● Germanischer Lloyd (GL) | Yes | |
| ● American Bureau of Shipping (ABS) | Yes | |
| ● Bureau Veritas (BV) | Yes | |
| ● Det Norske Veritas (DNV) | Yes | |
| ● Lloyds Register of Shipping (LRS) | Yes | |
| ● Nippon Kaiji Kyokai (Class NK) | Yes | |
| ● Polski Rejestr Statkow (PRS) | No | |
| Ambient conditions | ||
| Ambient temperature during operation | ||
| Operation (vertical installation) | ||
| — For vertical installation, min. | 0 °C | |
| — For vertical installation, max. | 50 °C | |
| Operation (max. tilt angle) | ||
| — At maximum tilt angle, min. | 0 °C | |
| — At maximum tilt angle, max. | 40 °C | |
| Operation (vertical installation, portrait format) | ||
| — For vertical installation, min. | 0 °C | |
| — For vertical installation, max. | 40 °C | |
| Operation (max. tilt angle, portrait format) | ||
| — At maximum tilt angle, min. | 0 °C | |
| — At maximum tilt angle, max. | 35 °C | |
| Ambient temperature during storage/transportation | ||
| ● min. | -20 °C | |
| ● max. | 60 °C | |
| Relative humidity | ||
| ● Operation, max. | 90 %; no condensation | |
| Operating systems | ||
| proprietary | No | |
| pre-installed operating system | ||
| ● Windows CE | Yes | |
| Configuration | ||
| Message indicator | Yes | |
| Alarm system (incl. buffer and acknowledgment) | Yes | |
| Process value display (output) | Yes | |
| Process value default (input) possible | Yes | |
| Recipe management | Yes | |
| Configuration software | ||
| ● STEP 7 Basic (TIA Portal) | No | |
| ● STEP 7 Professional (TIA Portal) | No | |
| ● WinCC flexible Compact | No | |
| ● WinCC flexible Standard | No | |
| ● WinCC flexible Advanced | No | |
| ● WinCC Basic (TIA Portal) | No | |
| ● WinCC Comfort (TIA Portal) | Yes; from V11 | |
| ● WinCC Advanced (TIA Portal) | Yes; from V11 | |
| ● WinCC Professional (TIA Portal) | Yes; from V11 | |
| Languages | ||
| Online languages | ||
| ● Number of online/runtime languages | 32 | |
| Project languages | ||
| ● Languages per project | 32 | |
| Functionality under WinCC (TIA Portal) | ||
| Libraries | Yes | |
| Applications/options | ||
| ● Web browser | Yes | |
| ● Pocket Word | Yes | |
| ● Pocket Excel | Yes | |
| ● PDF Viewer | Yes | |
| ● Media Player | Yes | |
| ● SIMATIC WinCC Sm@rtServer | Yes | |
| ● SIMATIC WinCC Audit | Yes | |
| Number of Visual Basic Scripts | Yes | |
| Task planner | ||
| ● time-controlled | Yes | |
| ● task-controlled | Yes | |
| Help system | ||
| ● Number of characters per info text | 70 | |
| Message system | ||
| ● Number of alarm classes | 32 | |
| ● Bit messages | Yes | |
| — Number of bit messages | 2 000 | |
| ● Analog messages | Yes | |
| — Number of analog messages | 50 | |
| ● S7 alarm number procedure | Yes | |
| ● System messages HMI | Yes | |
| ● System event, more (SIMATIC S7, SINUMERIK, SIMOTION, … ) | Yes | |
| ● Number of characters per message | 80 | |
| ● Number of process values per message | 8 | |
| ● Acknowledgment groups | Yes | |
| ● Message indicator | Yes | |
| ● Message buffer | ||
| — Number of entries | 256 | |
| — Circulating buffer | Yes | |
| — retentive | Yes | |
| — maintenance-free | Yes | |
| Recipe management | ||
| ● Number of recipes | 100 | |
| ● Data records per recipe | 200 | |
| ● Entries per data record | 200 | |
| ● Size of internal recipe memory | 512 kbyte | |
| ● Recipe memory expandable | Yes | |
| Variables | ||
| ● Number of variables per device | 1 024 | |
| ● Number of variables per screen | 50 | |
| ● Limit values | Yes | |
| ● Multiplexing | Yes | |
| ● Structures | Yes | |
| ● Arrays | Yes | |
| Images | ||
| ● Number of configurable images | 500 | |
| ● Permanent window/default | Yes | |
| ● Global image | Yes | |
| ● Pop-up images | Yes | |
| ● Slide-in images | Yes | |
| ● Image selection by PLC | Yes | |
| ● Image number in the PLC | Yes | |
| Image objects | ||
| ● Number of objects per image | 50 | |
| ● Text fields | Yes | |
| ● I/O fields | Yes | |
| ● Graphic I/O fields (graphics list) | Yes | |
| ● Symbolic I/O fields (text list) | Yes | |
| ● Date/time fields | Yes | |
| ● Switches | Yes | |
| ● Buttons | Yes | |
| ● Graphic display | Yes | |
| ● Icons | Yes | |
| ● Geometric objects | Yes | |
| Complex image objects | ||
| ● Number of complex objects per screen | 5 | |
| ● Alarm view | Yes | |
| ● Trend view | Yes | |
| ● User view | Yes | |
| ● Status/control | Yes | |
| ● Sm@rtClient view | Yes | |
| ● Recipe view | Yes | |
| ● f(x) trend view | Yes | |
| ● System diagnostics view | Yes | |
| ● Media Player | Yes | |
| ● HTML browser | No | |
| ● PDF display | Yes | |
| ● IP camera display | Yes | |
| ● Bar graphs | Yes | |
| ● Sliders | Yes | |
| ● Pointer instruments | Yes | |
| ● Analog/digital clock | Yes | |
| Lists | ||
| ● Number of text lists per project | 300 | |
| ● Number of entries per text list | 30 | |
| ● Number of graphics lists per project | 100 | |
| ● Number of entries per graphics list | 30 | |
| Archiving | ||
| ● Number of archives per device | 10 | |
| ● Number of entries per archive | 10 000 | |
| ● Message archive | Yes | |
| ● Process value archive | Yes | |
| ● Archiving methods | ||
| — Sequential archive | Yes | |
| — Short-term archive | Yes | |
| ● Memory location | ||
| — Memory card | Yes | |
| — USB memory | Yes | |
| — Ethernet | Yes | |
| ● Data storage format | ||
| — CSV | Yes | |
| — TXT | Yes | |
| — RDB | Yes | |
| Security | ||
| ● Number of user groups | 50 | |
| ● Number of user rights | 32 | |
| ● Number of users | 50 | |
| ● Password export/import | Yes | |
| ● SIMATIC Logon | Yes | |
| Logging through printer | ||
| ● Alarms | Yes | |
| ● Report (shift log) | Yes | |
| ● Hardcopy | Yes | |
| ● Electronic print to file | Yes; PDF, HTML | |
| Character sets | ||
| ● Keyboard fonts | ||
| — US English | Yes | |
| Transfer (upload/download) | ||
| ● MPI/PROFIBUS DP | Yes | |
| ● USB | Yes | |
| ● Ethernet | Yes | |
| ● using external storage medium | Yes | |
| Process coupling | ||
| ● S7-1200 | Yes | |
| ● S7-1500 | Yes | |
| ● S7-200 | Yes | |
| ● S7-300/400 | Yes | |
| ● LOGO! | Yes | |
| ● WinAC | Yes | |
| ● SINUMERIK | Yes; with SINUMERIK option package | |
| ● SIMOTION | Yes | |
| ● Allen Bradley (EtherNet/IP) | Yes | |
| ● Allen Bradley (DF1) | Yes | |
| ● Mitsubishi (MC TCP/IP) | Yes | |
| ● Mitsubishi (FX) | Yes | |
| ● OMRON (FINS TCP) | No | |
| ● OMRON (Host Link) | Yes | |
| ● Modicon (Modbus TCP/IP) | Yes | |
| ● Modicon (Modbus RTU) | Yes | |
| ● OPC UA Client | Yes | |
| ● OPC UA Server | Yes | |
| Service tools/configuration aids | ||
| ● Backup/Restore manually | Yes | |
| ● Backup/Restore automatically | Yes | |
| ● Simulation | Yes | |
| ● Device switchover | Yes | |
| Peripherals/Options | ||
| Printer | Yes | |
| SIMATIC HMI MM memory card: Multi Media Card | Yes; Up to 128 MB | |
| SIMATIC HMI SD memory card: Secure Digital memory card | Yes; Up to 2 GB | |
| SIMATIC HMI CF memory card Compact Flash Card | No | |
| USB memory | Yes | |
| SIMATIC IPC USB Flashdrive (USB stick) | Yes; Up to 16 GB | |
| SIMATIC HMI USB stick | Yes; Up to 8 GB | |
| Network camera | Yes | |
| Mechanics/material | ||
| Enclosure material (front) | ||
| ● Plastic | Yes | |
| ● Aluminum | No | |
| ● Stainless steel | No | |
| Dimensions | ||
| Width of the housing front | 140 mm | |
| Height of housing front | 116 mm | |
| Mounting cutout, width | 124 mm | |
| Mounting cutout, height | 100 mm | |
| mounting depth | 48 mm | |
| Weights | ||
| Weight (without packaging) | 0.6 kg | |
| Weight (with packaging) | 0.7 kg | |
Datasheet: PDF
Why Choose Voltec Engineering Limited?
At Voltec Engineering Limited, we are proud to be the authorized distributor of Leuze Electronic in Bangladesh. As a trusted Leuze sensor supplier in Bangladesh and leading industrial automation supplier Bangladesh, we deliver photoelectric sensors, diffuse sensors, retroreflective sensors, through-beam sensors, barcode scanners, safety light curtains, inductive sensors, proximity sensors, optical sensors, and machine safety products.
We ensure top-quality Leuze sensors in Bangladesh, backed by exceptional technical support and a wide range of automation solutions in Bangladesh. Our experienced team provides guidance on sensor selection, PLC programming, HMI integration, VFD and inverter panels, and automation project design to meet your requirements. With ready stock and fast delivery, Voltec Engineering Limited is your reliable Leuze distributor Bangladesh.
For assistance or to place an order, don’t hesitate to contact us. Voltec Engineering is here to support you with Leuze Electronic Bangladesh, photo sensor Bangladesh, Sick Sensor Supplier in Bangladesh, automation spare parts Bangladesh, SIEMENS Fail-safe CPU, AUTONICS Inductive Proximity Sensors, AUTONICS Photoelectric Proximity Sensors, SIEMENS Basic & Advanced Controllers, PLC and HMI supplier Bangladesh, VFD and inverter supplier Bangladesh, and industrial sensors Bangladesh ensuring efficiency, precision, and reliability in your operations.
Related products
