Sick IQC12-04BPPKQ8SA71

SICK Inductive Proximity Sensors IQC12-04BPPKQ8SA71 | Part no: 1083798

  • Sensing range (max.): 0 mm – 4 mm (Adjustable)
  • Connection type: Cable with M12 male connector, 4-pin, 0.2 m
  • Switching output: PNP
  • Output function: NC/NO
  • Switching frequency: 1000 Hz
  • Installation type: Flush



For Price Call: 01329727092
Email: sales@voltecbd.com
Category:
Tags:

Description

SICK Inductive Proximity Sensors IQC12-04BPPKQ8SA71 | Part no: 1083798

SICK Inductive Proximity Sensors

SICK Inductive Proximity Sensors Supplier in Bangladesh

IMC

Inductive distance sensors with IO-Link for industrial use

The inductive, intelligent, and, thanks to IO-Link 1.1, communication-enabled IMC proximity sensors offer a whole host of new options to make handling applications easier and more reliable in every industry. Up to four individual switching points or windows including the hysteresis can be set. Equipped with two freely programmable switching end stages, an IMC can therefore replace several conventional devices. Adjustable switch-on and switch-off delays help to reliably suppress unwanted switching pulses in harsh environments. The additional on-board functions, such as logic modules, temperature measurement, counters, or time measurement enable complex tasks to be completed with ease directly in the sensor.



IMC AT A GLANCE
Benefits
  • Advanced diagnostic options ensure stable processes
  • Programmable switching thresholds and windows make predictive maintenance easier and reduce machine downtimes
  • Switching point teaching enables precise object positioning without the need for time-consuming adjustment
  • Reduced costs as fewer sensors or sensor variants are required
  • Stable signals thanks to integrated debounce function
  • Reduced project planning and cabling work as complex tasks are easy to implement directly in the process
  • Future-proof thanks to IO-Link 1.1 communication
Features
  • Types: M8 to M30; IQ10 and IQ12
  • Four programmable switching points or windows at an Sn of up to 20 mm
  • Freely programmable output function
  • Enclosure rating: IP68, IP69K
  • Temperature range: –40 °C to +75 °C
  • Rugged stainless-steel or VISTAL housing
  • Logic, counter, time measurement, or temperature monitoring function
  • IO-Link 1.1

Technical details-

Features

Housing Rectangular
Dimensions (W x H x D) 12 mm x 40 mm x 26 mm
Sensing range Sn 0 mm … 4 mm 1)
Safe sensing range Sa 3.24 mm
Number of switching points Up to 4 adjustable switching points or windows
Switching modes Single point, Window mode, Two point mode, Visual adjustment indicator
Switching frequency Qint.1 / Qint.2 on Pin2 1,000 Hz
Installation type Flush
Connection type Cable with M12 male connector, 4-pin, 0.2 m 2)
Switching output PNP
Switching output detail PNP
Output Q/C Switching output or IO-Link mode
Output MFC Switching output or input
Output function NC / NO
Output characteristic Programmable
Electrical wiring DC 4-wire
Enclosure rating IP68 3)
Special features Smart Task
Pin 2 configuration External input, Teach-in, switching signal

1) Adjustable.

2) With gold plated contact pins.

3) According to EN 60529.



Mechanics & Electronics

Supply voltage 10 V DC … 30 V DC 1)
Ripple ≤ 10 %
Voltage drop ≤ 2 V 2)
Hysteresis Programmable 3)
Reproducibility ≤ 5 % 4)

5)
Temperature drift (of Sr) ± 10 %
EMC According to EN 60947-5-2
Continuous current Ia ≤ 200 mA 6)
No load current 35 mA
Cable material PUR
Short-circuit protection ✔
Power-up pulse protection ✔
Shock and vibration resistance 30 g, 11 ms / 10 … 55 Hz, 1 mm
Ambient operating temperature –25 °C … +75 °C
Housing material Plastic, VISTAL®
Sensing face material Plastic, VISTAL®
Tightening torque, max. < 1 Nm
Teach-in accuracy +/- 3% of Sr
Resolution, typical (range) 20 μm (0 mm … 4 mm)
Resolution, maximum (area) 40 μm (0 mm … 4 mm)

1) IO-Link mode: 18 VDC … 30 VDC.

2) At Ia max.

3) To comply with EN 60947-5-2, a hysteresis of approx. 10% must be set.

4) Supply voltage UB and constant ambient temperature Ta.

5) Of Sr.

6) 200 mA total for both switching outputs.

Datasheet: PDF
