Pepperl+Fuchs Photoelectric Sensors | RLK28-55-Z/31/116
- Functional principle: Retroreflective sensor
- Effective detection range: 0 – 17 m
- Connection type: M16 x 1.5 cable gland
- Switching type: Light/dark on switchable
- Switching frequency: 25 Hz
- Light type: Modulated visible red light
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
Pepperl+Fuchs Photoelectric Sensors | RLK28-55-Z/31/116
Pepperl+Fuchs Photoelectric Sensors
Pepperl+Fuchs Photoelectric Sensors Supplier in Bangladesh
Photoelectric Sensors
Pepperl+Fuchs offers an extensive portfolio of standard photoelectric sensors and measurement technology precisely engineered for the demands of industrial automation. Various sensing modes, including conventional thru-beam sensors and diffuse mode sensors to high-performance distance sensors, are available in miniature, standard, and specialized designs. This forward-thinking portfolio concept guarantees maximum flexibility for users.
Aside from machine and plant construction and the automotive industry, photoelectric sensors are primarily used in material handling, mobile equipment, and the packaging and electronics industries.
- Universal series with highly versatile fields of use
- Resistant against noise: reliable operation under all conditions
- Programmable time function GAN, GAB, IAB, as well as GAN-GAB and GAN-IAB as double function
- Version with red light
- Version with relay output
Technical details-
General specifications
| Effective detection range | 0 … 17 m | |
| Reflector distance | 0.05 … 17 m | |
| Threshold detection range | 21 m | |
| Reference target | H85-2 reflector | |
| Light source | LED | |
| Light type | modulated visible red light | |
| Polarization filter | yes | |
| Diameter of the light spot | approx. 290 mm at a distance of 17 m | |
| Opening angle | emitter 1.2° receiver 2° |
|
| Ambient light limit | 80000 Lux |
Mechanical specifications
| Degree of protection | IP64 | ||||||||||
| Connection | terminal compartment with 8 spring-loaded terminals for wire cross section 0.5 … 1.5 mm2 , Insulation stripping 7.5 … 8.5 mm , M16 x 1.5 cable gland | ||||||||||
| Material | |||||||||||
|
|||||||||||
| Mass | 112 g | ||||||||||
| Dimensions | |||||||||||
|
|||||||||||
Datasheet: PDF
