Pepperl+Fuchs Photoelectric Sensors | OBE10M-R103-S2EP-IO-0,3M-V1
- Functional principle: Thru-beam sensor
- Effective detection range: 0 m – 10 m
- Connection type: 300 mm fixed cable with M12 x 1, 4-pin connector
- Switching type: Adjustable
- Switching frequency: 1000 Hz
- Light type: Modulated visible red light
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
Pepperl+Fuchs Photoelectric Sensors | OBE10M-R103-S2EP-IO-0,3M-V1
Pepperl+Fuchs Photoelectric Sensors
Pepperl+Fuchs Photoelectric Sensors Supplier in Bangladesh
Photoelectric Sensors
Pepperl+Fuchs offers an extensive portfolio of standard photoelectric sensors and measurement technology precisely engineered for the demands of industrial automation. Various sensing modes, including conventional thru-beam sensors and diffuse mode sensors to high-performance distance sensors, are available in miniature, standard, and specialized designs. This forward-thinking portfolio concept guarantees maximum flexibility for users.
Aside from machine and plant construction and the automotive industry, photoelectric sensors are primarily used in material handling, mobile equipment, and the packaging and electronics industries.
- Miniature design with versatile mounting options
- IO-Link interface for service and process data
- Various frequencies for avoiding mutual interference (cross-talk immunity)
- Extended temperature range
-40 °C … 60 °C - High degree of protection IP69K
Technical details-
General specifications
| Effective detection range | 0 … 10 m | |
| Threshold detection range | 12.5 m | |
| Light source | LED | |
| Light type | modulated visible red light | |
| LED risk group labelling | exempt group | |
| Diameter of the light spot | approx. 65 mm at a distance of 1 m | |
| Opening angle | 3.7 ° | |
| Ambient light limit | EN 60947-5-2 : 30000 Lux |
Mechanical specifications
| Degree of protection | IP67 / IP69 / IP69K | ||||||||||
| Connection | 300 mm fixed cable with M12 x 1, 4-pin connector | ||||||||||
| Material | |||||||||||
|
|||||||||||
| Mass | Emitter: approx. 23 g receiver: approx. 23 g | ||||||||||
| Dimensions | |||||||||||
|
|||||||||||
| Cable length | 0.3 m | ||||||||||
Datasheet: PDF
