Pepperl+Fuchs Photoelectric Sensors | ML100-8-W-200-RT/95/103
- Functional principle: Diffuse mode sensor
- Effective detection range: 0 – 200 mm
- Connection type: plug M8 x 1 , 4-pin
- Switching type: Adjustable
- Switching frequency: 1000 Hz
- Light type: Modulated visible red light
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
Pepperl+Fuchs Photoelectric Sensors | ML100-8-W-200-RT/95/103
Pepperl+Fuchs Photoelectric Sensors
Pepperl+Fuchs Photoelectric Sensors Supplier in Bangladesh
Photoelectric Sensors
Pepperl+Fuchs offers an extensive portfolio of standard photoelectric sensors and measurement technology precisely engineered for the demands of industrial automation. Various sensing modes, including conventional thru-beam sensors and diffuse mode sensors to high-performance distance sensors, are available in miniature, standard, and specialized designs. This forward-thinking portfolio concept guarantees maximum flexibility for users.
Aside from machine and plant construction and the automotive industry, photoelectric sensors are primarily used in material handling, mobile equipment, and the packaging and electronics industries.
- Miniature design
- Easy to use
- Very bright, highly visible light spot
- Full metal thread mounting
- Highly visible LEDs for Power ON and switching state
- Not sensitive to ambient light
Technical details-
General specifications
| Detection range | 0 … 200 mm | |
| Adjustment range | 15 … 200 mm | |
| Reference target | standard white , 200 mm x 200 mm | |
| Light source | LED | |
| Light type | modulated visible red light | |
| Polarization filter | no | |
| Diameter of the light spot | approx. 170 mm at a distance of 200 mm | |
| Optical face | frontal | |
| Ambient light limit | EN 60947-5-2:2007+A1:2012 |
Mechanical specifications
| Degree of protection | IP67 | ||||||||||
| Connection | plug M8 x 1 , 4-pin | ||||||||||
| Material | |||||||||||
|
|||||||||||
| Mass | approx. 10 g | ||||||||||
| Tightening torque, fastening screws | 0.6 Nm | ||||||||||
| Dimensions | |||||||||||
|
|||||||||||
Datasheet: PDF
