Connection Cable

Leuze Connection Cable KD U-M8-4A-V1-050 , 50130850

Add to Wishlist
Add to Wishlist
  • Type of connection: Connector.
  • Operating voltage: Max. 30 V AC/DC.
  • Number of conductors : 4.
  • Cable length: 5m.
  • Wire insulation : PVC.
  • Thread size: M8.
  • Type: Female.
  • No. of pins: 4 -pin.
  • Version Axial: Connector. LED: No.
  • Lock: Screw fitting.
  • Nickel-plated diecast zinc.
  • Recommended torque 0.6 Nm.
  • Self-locking.
Category:
Tags:

Description

Leuze Connection Cable KD U-M8-4A-V1-050 , 50130850

Connection Cable

Specifications:-

Basic Data:-

Application Chemical resistant

Electrical Data:-
    Performance Data:-

Operating voltage Max. 30 V AC/DC

Outputs:-
Switching Outputs:-
Time Behavior:-
Connection :-


Type of connection Connector
Thread size M8
Type Female
No. of pins 4 -pin
Version Axial
Connector, LED No
Lock Screw fitting, nickel-plated diecast zinc, recommended torque 0.6 Nm, self-locking

          Connection 2:-

Type of connection Open end

Cable Properties:-

Number of conductors 4 Piece(s)
Sheathing color Black
Shielded No
Silicone-free Yes
Cable length 5,000 mm
Sheathing material PVC
Wire insulation PVC
Suitability for drag chains No
Properties of the outer sheathing Free of CFC, cadmium, silicone and lead, easily machine-processable
Resistance of the outer sheathing Good oil, gasoline and chemical resistance, flame retardant in accordance with UL 1581 VW1 / CSA FT1

Mechanical Data:-

Width across flats 9 mm
Net weight 166 g
Bending radius, flexible laying, min. Min. 10 x cable diameter
Bending radius, stationary laying, min. Min. 5 x cable diameter

Environmental Data:-

Ambient temperature, operation, flexible use -5 … 80 °C
Ambient temperature, operation, stationary use -30 … 80 °C

Model:-

KD U-M8-3A-T0-050 F+B, KD U-M8-3A-T0-020 F+B, S GB-M12-8A-M-SK ,S ET-M12-4W-M,S PL-M12-5A-K ,KY IVS 1048-IL, KY-HS-DDS-D9AJ2ARAA-020-T1 ,KDS S-12-CA-M12-5A-P1-004-78X ,KDS U-M8-3A-M8-3W-P1-006-A01 ,KDS U-M8-3A-M8-3W-P1-003-A01 ,KDS S-M12-5A-M12-5A-P1-200 ,KDS PB-M12-4A-M12-8A-P0-020,KDS U-M8-4A-M8-4A-P1-030 KSS ET-M12-4W-M12-4W-P7-100,KSS ET-M12-4W-M12-4W-P7-020,KDS S-M12-CA-M12-CA-P1-003 ,KDS DN-M12-5W-M12-5W-P3-150 .

Data Sheet:-Pdf
