IFM Capacitive Sensor KD5018
IFM Capacitive Sensor KD5018 supplier in Bangladesh
IFM Senor KD5018 | KDE3060-FPKG/NI
Capacitive sensors
Capacitive sensors are used for the non-contact detection of any objects. In contrast to inductive sensors, which only detect metallic objects, capacitive sensors can also detect non-metallic materials.
Typical applications are in the wood, paper, glass, plastic, food, chemical and semiconductor industries.
- High noise immunity
- Sensing range adjustable by means of potentiometer or teach button
- Plastic or metal housings for different applications
- Sensors for position and level detection
- Accessories for mounting on tanks or sight glasses
Technical Details:
Product characteristics
| Electrical design |
PNP |
| Output function |
normally open / normally closed; (selectable) |
| Sensing range[mm] |
60 |
| Housing |
rectangular |
| Dimensions[mm] |
105 x 80 x 40 |
Electrical data
| Operating voltage[V] |
10…36 DC |
| Current consumption[mA] |
15; (24 V) |
| Protection class |
II |
| Reverse polarity protection |
yes |
Outputs
| Electrical design |
PNP |
| Output function |
normally open / normally closed; (selectable) |
| Max. voltage drop switching output DC[V] |
2.5 |
| Permanent current rating of switching output DC[mA] |
250 |
| Switching frequency DC[Hz] |
10 |
| Short-circuit proof |
yes |
| Overload protection |
yes |
Detection zone
| Sensing range[mm] |
60 |
| Real sensing range Sr[mm] |
60 ± 10 % |
| Operating distance[mm] |
0…48.6 |
Accuracy / deviations
| Correction factor |
glass: 0.4 / water: 1 / ceramics: 0.2 / PVC: 0.2 |
| Hysteresis[% of Sr] |
1…15 |
| Switch point drift[% of Sr] |
-15…15 |
Operating conditions
| Ambient temperature[°C] |
-25…80 |
| Protection |
IP 65 |
| Increased immunity |
yes |
Mechanical data
| Weight[g] |
297.5 |
| Housing |
rectangular |
| Mounting |
non-flush mountable |
| Dimensions[mm] |
105 x 80 x 40 |
| Materials |
PPE modified |
Displays / operating elements
| Display |
| switching status |
1 x LED, yellow |
|
Accessories
| Items supplied |
| spring washers: 4 |
| cylinder screws: 4 |
|
Electrical connection
| terminals |
…2.5 mm²; Cable sheath: Ø 7…13 mm; Cable gland: M20 X 1.5 |
Datasheet: PDF
