DATALOGIC/DATASENSING Capacitive Proximity Sensors | CE2/0P-1A
- Sensing range (max.): 1.5 – 10 mm
- Connection type: 2m PVC cable
- Switching output: PNP
- Output function: NO+NC
- Switching frequency: 300 Hz
- Installation type: Shielded
For Price Call: 01329727092
Email: sales@voltecbd.com
Description
DATALOGIC/DATASENSING Capacitive Proximity Sensors | CE2/0P-1A
DATALOGIC/DATASENSING Capacitive Proximity Sensors
DATALOGIC/DATASENSING Capacitive Proximity Sensors supplier in Bangladesh
CE AT A GLANCE
Detection of all types of materials: solids, liquids, powders.
- Models with or without self-monitoring
- Sensitivity adjustment with trimmer
- NO+NC complementary output
- Stainless steel housing
- IP65 protection degree
- Complete protection against electrical damages
- Axial cable exit or M12 plastic plug cable exit
Technical details-
| Nominal sensing distance | 1,5…10mm |
| Thermal drift of Sr | < 20% |
| Repeat Accuracy | 5% |
| Sensitivity adjustment | Yes |
| Hysteresis | ≤ 20% |
| Output type | PNP with self monitoring |
| Output Function | NO + NC |
| Switching frequency | 300Hz |
| Operating Voltage | 10..30Vdc |
| No-Load supply current | ≤ 17mA |
| Load current | ≤ 100mA |
| Leakage current | ≤ 1μA |
| Output voltage drop | 1,5V – max. IL=100mA |
| Max ripple content | ≤15% |
| LED indicators | Yellow LED (object detected) |
| Time delay before availability | ≤ 200ms |
| Short-circuit protection | Yes, autoreset |
| Reverse Polarity Protection | Yes |
| Impulsive Overvoltage Protection | Yes |
| Dimensions | ø20 / L = 80mm |
| Mounting | Shielded |
| Housing material | AISI 303 Stainless Steel |
| Weight | 200g |
| Connections | 2m PVC cable |
| Active Head Material | LCP |
| Operating temperature | -25°C…+70°C |
| Diameter/Dimension | ø20 |
Datasheet: PDF
