BALLUFF BOS R072K-PU-RX10-S75

BALLUFF Photoelectric Proximity Sensors BOS02JE | BOS R072K-PU-RX10-S75

  • Functional principle: Through-beam sensor
  • Sensing range (max.): 0 – 20 mm
  • Connection type: Connector, M8x1-Male, 4-pin
  • Output Type: PNP
  • Output function: NO/NC
  • Light type: LED, red light



For Price Call: 01329727092
Email: sales@voltecbd.com
Category:
Tags:

Description

BALLUFF Photoelectric Proximity Sensors BOS02JE | BOS R072K-PU-RX10-S75

BALLUFF Photoelectric Proximity Sensor

BALLUFF Photoelectric Proximity Sensors supplier in Bangladesh

Cubic through-beam sensors Entry Line with excellent price-performance ratio

Through-beam sensors from Balluff serve to detect objects reliably, regardless of surface, color, material – even with a heavy gloss finish. They consist of separate transmitter and receiver units that are attuned to each other. When an object interrupts the light beam, this causes a change in the output signal in the receiver. Absolute reliability.

BALLUFF Photoelectric Proximity Sensors at a glance

Special Features

  • Ideal for positioning tasks thanks to excellent reproducibility
  • Extremely resistant to contamination and has a large functional reserve
  • Ideally suited for large operating ranges
  • Transmitter and receiver in separate housings

Technical details-

Features

Property Value
Series 21M
Dimension 15 x 50 x 42.5 mm
Interface

PNP normally open (NO)



PNP normally closed (NC)
Principle of operation Photoelectric sensor
Principle of optical operation Retroreflective sensor
Beam characteristic Collimated
Light type Laser red light
Range 0…20 m
Connection Connector, M12x1-Male, 4-pin
Housing material

Zinc, Die casting, Powder coated



Aluminium
Material sensing surface PMMA
Operating voltage Ub 10…30 VDC
Approval/Conformity CE, UKCA, cULus, WEEE



Datasheet: PDF
